Schneider BMXDDM16025 Discrete Hybrid IO Modules

The Schneider Electric BMXDDM16025 is a hybrid discrete I/O module designed for the Modicon M340 automation platform. Combining 8 digital inputs and 8 solid-state (transistor) outputs, this module offers versatile signal control for compact and high-performance industrial automation solutions. It supports 24 V DC logic, features fast response times, and is ideal for applications requiring both input detection and output actuation in one device.

Key Features

• 16 discrete channels: 8 inputs and 8 transistor outputs

• 24 V DC input and output voltage

• Sink/source input compatibility

• High-speed switching outputs (0.5 A per channel)

• LED status indicators for each channel

• Compact and modular design

• Supports hot swapping for minimal downtime

• Short-circuit protection on outputs

Technical Specifications

Industry Applications

• Packaging machinery

• Assembly line automation

• Process monitoring and control

• Material handling systems

• Building automation

• Water and wastewater treatment systems

Advantages

• Integrated I/O: Combines input and output in a single module, saving rack space

• High-Speed Performance: Quick response times for real-time control

• Durable Outputs: Solid-state transistor outputs for extended lifecycle

• Built-in Diagnostics: Instant status feedback reduces troubleshooting time

• Modicon M340 Compatibility: Seamless integration into Schneider automation systems

• Compact Design: Ideal for space-constrained control panels

• Enhanced Safety: Output protection against short circuits and overloads

• Hot Swappable: Enables maintenance without system downtime

Frequently Asked Questions (FAQ)

1. What type of I/O does the BMXDDM16025 module support?

   It supports 8 digital inputs and 8 transistor (digital) outputs.

2. Is this module compatible with Modicon M340 PLCs?

   Yes, it is specifically designed for the Modicon M340 platform.

3. What is the rated voltage for input and output?

   Both inputs and outputs operate at 24 V DC.

4. Are the outputs relay or transistor-based?

   The outputs are solid-state (transistor) type for fast switching.

5. What protection features are included?

   It includes short-circuit and overload protection on the output channels.

6. Can I hot swap the module during system operation?

   Yes, it supports hot swapping without shutting down the system.

7. How many modules can I install in one M340 rack?

   This depends on the power and I/O capacity of your configuration, but several can be accommodated.

8. Is there LED status for each channel?

   Yes, each I/O channel has an individual LED indicator.

9. What are the module dimensions?

   Package size: 51 x 116 x 118mm.

10. How much does the module weigh?

    Approximately 0.135 kg.
