GE T35A00HCHF8CH6UM8CP6CU8AWXX Transformer Relay

GE T35A00HCHF8CH6UM8CP6CU8AWXX is a microprocessor-based transformer relay. It provides comprehensive protection for power transformers. This relay features a wide range of protection functions, including:

• Differential protection
• Overcurrent protection
• Restraint overcurrent protection
• Second harmonic restraint overcurrent protection
• Zero sequence overcurrent protection
• Magnetizing inrush protection
• Thermal overload protection
• Sudden pressure protection
• Voltage protection
• Frequency protection
• Breaker failure protection
• Synchrocheck protection

Communication and Metering Functions

The relay includes a variety of communication and metering functions:

• SCADA compatibility
• Event reporting
• Fault records
• Metering data

Applications

The GE T35A00HCHF8CH6UM8CP6CU8AWXX is designed for use in various applications:

• Industrial power systems
• Utility power systems
• Renewable energy systems

Technical Specifications

The relay has the following technical specifications:

• Rated voltage: 35 kV
• Rated frequency: 50/60 Hz
• Accuracy class: 0.5
• Burden: 2 VA
• Operating temperature range: -40°C to +85°C
• Storage temperature range: -55°C to +90°C
• Humidity: 0% to 95% RH (non-condensing)
• Altitude: up to 3,000 m

Additional Features

The relay also offers additional features:

• Dual microprocessor design for enhanced reliability
• Self-test function ensures proper operation
• Parameter setting via front panel or RS-232 port
• Store event reports in non-volatile memory
• Transmit metering data via RS-232 or Modbus RTU

Benefits

The GE T35A00HCHF8CH6UM8CP6CU8AWXX relay provides many benefits for power transformers. It offers a wide range of protection and communication functions. Additionally, it is reliable and easy to use. You can employ it in a variety of applications, such as:

• Power transformers
• Generator transformers
• Distribution transformers
• Interconnection transformer
