Feedback Aggregation: The GE IS220PPDAH1A gathers feedback signals from up to six power distribution boards or equivalent sources.

Data Conditioning: It processes and adjusts incoming feedback signals to ensure compatibility with the control system.

Redundancy: The unit offers a secondary Ethernet interface, enhancing system reliability.

Plug-and-Play Integration: The IS220PPDAH1A employs electronic IDs for automatic recognition of connected power distribution boards.

IONet Output: It provides accurate feedback data to connected boards via the IONet network.

Hardware Configuration

Host Board: The PPDA I/O pack typically resides on a Mark VIe Control Power Distribution Module (JPDS, JPDM, JPDG, or JPDC).

Interconnection: It utilizes 50-pin ribbon cable jumpers for connecting to other boards.

Processor Board: The PPDAH1A model incorporates a BPPB processor board. ControlST software V04.07 and later support the functionally compatible BPPC processor board for the PPDAHIB model.

Compatibility

Power Distribution Boards: It is compatible with JPDB, JPDE, and JPDF feedback signals.

Software: It functions with ControlST software V04.07 and later when using the BPPC processor board.

System Integration

The PPDA ensures accurate and reliable power distribution monitoring within the Mark VIe system. It aggregates feedback data from multiple sources and provides a redundant communication channel. Thus, it contributes significantly to overall system performance and availability.

Technical Specifications

Part Number: IS220PPDAH1A

Manufacturer: General Electric

Series: Mark VIe

Product Type: I/O Pack

Input Voltage: 335 V DC

Input Current: 2.5 A

Output Voltage: 24 V DC

Output Current: 5 A

Operating Temperature: -40°C to +70°C

Storage Temperature: -55°C to +85°C

Humidity: 5% to 95% RH, non-condensing

Vibration: 0.05 g RMS, 57 to 2,000 Hz

Shock: 5 g, 22 ms half-sine

EMC: Meets EN 50081-1, EN 50082-2

Dimensions: 7.5 in x 6.0 in x 2.5 in

Weight: 3.0 lb
