Woodward PCU2000ETH ETHERNET CARD

The Woodward PCU2000ETH Ethernet Card is designed as a high-performance communication module for integration with the PCU2000 controller system. It enables robust and reliable Ethernet-based communication, facilitating real-time monitoring, control, and data exchange between industrial devices. The card supports multiple networking protocols, enhancing flexibility in industrial automation, power generation, and turbine control applications.

Product Specifications

Product Applications

• Integration with Woodward PCU2000 controllers in turbine and generator systems

• Industrial automation networks for monitoring and control of process equipment

• Remote access for diagnostics, configuration, and firmware updates

• Data acquisition systems in power plants and distributed energy systems

• Networking of multiple controllers for synchronized control

• SCADA system integration for real-time monitoring

Product Advantages

• High-speed Communication: Provides fast 10/100 Mbps Ethernet connectivity for real-time control.

• Protocol Flexibility: Supports Modbus TCP/IP and EtherNet/IP to ensure compatibility with diverse industrial networks.

• Robust Design: Operates reliably in harsh industrial environments, with a wide temperature and humidity range.

• Easy Integration: Directly plugs into the PCU2000 system without additional hardware requirements.

• LED Status Indicators: Simplifies network diagnostics and troubleshooting.

• Scalability: Facilitates connection of multiple devices in a networked control system.
