General Electric IC660TBD022 Terminal Assemblies

The GE IC660TBD022 Terminal Assembly is a high-performance component from the Genius I/O series manufactured by GE Intelligent Platforms (formerly GE Fanuc). This unit is designed to function within distributed control systems and industrial automation networks, specifically to interface field devices with control processors through Genius I/O communication.

The IC660TBD022 is a 32-circuit Terminal Assembly designed for use with discrete I/O blocks. It supports either sourcing or sinking I/O and is engineered for robust operation in harsh industrial environments. The Terminal Assembly serves as the point of field wiring connection and integrates tightly with the block electronics to form a complete Genius I/O block assembly.

Its rugged design, ease of wiring, and solid compatibility with GE’s automation infrastructure make it a reliable component for complex and mission-critical industrial automation systems.

Product Specifications

Applications

• Factory Automation: Used in manufacturing lines for process monitoring, equipment control, and inter-device communication.

• Material Handling Systems: Interfaces with sensors, switches, and actuators in conveyor or sorting systems.

• Utilities and Power Plants: Ensures reliable I/O communication in demanding utility control environments.

• Oil and Gas Facilities: Robust enough for deployment in upstream and downstream automation.

• Automotive Assembly Lines: Coordinates I/O between robotic equipment and PLCs.

• Food and Beverage Plants: Withstands wash-down and sanitary requirements when installed in protective enclosures.

Product Advantages

• High Reliability: Designed to operate reliably in harsh industrial environments with wide temperature and humidity ranges.

• Ease of Maintenance: Removable wiring terminal blocks allow easy field service and installation.

• Modular Compatibility: Easily integrates with other GE Genius I/O components and programmable automation controllers.

• Cost-Efficient: Lowers wiring complexity and installation time through streamlined terminal connections.

• Versatile Mounting: Can be mounted in various configurations (panel or DIN rail) to fit control cabinet layouts.

• Field-Proven: Time-tested component in industrial settings with a long service life.

• Redundancy Options: Supports fault-tolerant configurations when used with redundant I/O setups.

• Safety Features: Overload and short-circuit protection designed into connected I/O blocks.

• Interoperability: Compatible with a wide range of GE PLCs and automation systems.

• Scalability: Supports a large number of discrete input/output points, ideal for scaling complex systems.

FAQ

1. What is the function of the IC660TBD022 Terminal Assembly?

   It serves as the field wiring interface for GE Genius I/O blocks, allowing 32 discrete I/O connections.

2. Is the IC660TBD022 compatible with other Genius I/O blocks?

   Yes, it is designed to work with GE’s IC660 series discrete I/O blocks.

3. Can this terminal assembly be used in outdoor environments?

   Only if it’s housed in a properly rated enclosure; the terminal itself is rated IP20.

4. What type of wiring does it support—sourcing or sinking?

   It supports both sourcing and sinking configurations depending on the I/O block used.

5. What is the maximum current capacity per circuit?

   Each circuit can handle up to 2 Amps of current.

6. How is the IC660TBD022 mounted?

   It can be mounted on DIN rails or panels using standard hardware.

7. What are the dimensions of this terminal assembly?

   150 mm (H) x 145 mm (W) x 60 mm (D).

8. Does the terminal assembly include protection against electrical faults?

   Protection is built into the I/O blocks, not the terminal assembly itself.

9. What certifications does the IC660TBD022 have?

   It is UL-listed, CE-marked, CSA-certified, and RoHS compliant.

10. Is the terminal assembly hot-swappable?

    No, field wiring should only be connected or disconnected when the power is off.
