ABB AFPS-01C 64711245 Inverter Accessories

The ABB AFPS-01C (64711245) is a dedicated fieldbus adapter module designed for ABB’s ACS series drives. As part of the ABB inverter accessories portfolio, the AFPS-01C facilitates seamless communication between ABB frequency converters and external industrial automation systems using various fieldbus protocols. This module ensures reliable system integration, enhances network compatibility, and supports a variety of industrial applications where precise control and monitoring are essential.

Engineered to the highest industrial standards, the AFPS-01C is robust, compact, and user-friendly. It is an ideal interface expansion accessory for applications in factory automation, building services, material handling, and processing industries. Its plug-and-play capability and wide protocol support ensure adaptability and fast commissioning in diverse environments.

Technical Specifications

Applications

The ABB AFPS-01C adapter module is designed to extend the communication capabilities of ABB drives in numerous industrial environments. Common applications include:

• Factory Automation: Integrates ABB drives into programmable logic controller (PLC)-based systems via PROFIBUS.

• Material Handling Systems: Enhances motor control in conveyor lines, cranes, and hoists.

• HVAC and Building Automation: Enables precise control of fans, pumps, and compressors.

• Water and Wastewater: Assists in automated control of treatment plant processes.

• Food and Beverage: Facilitates hygienic process control under network supervision.

• Pulp and Paper Industry: Helps in the automation of complex paper processing machinery.

Product Advantages

• Seamless Integration: Offers native support for PROFIBUS DP, one of the most widely adopted industrial fieldbus protocols.

• Plug-and-Play Commissioning: No complex configuration required; rapid setup via ABB drive interface.

• Compact and Lightweight: Minimal spatial footprint makes installation in tight enclosures easier.

• Diagnostic LED Indicators: Quick visual feedback of operational and fault status simplifies troubleshooting.

• Reliable Operation: Designed for harsh industrial conditions, with excellent thermal and vibration tolerance.

• Enhanced Compatibility: Fully compatible with ABB ACS drive series, providing flexibility across multiple projects.

• Long Lifecycle Support: Backed by ABB’s global service and support network, ensuring long-term reliability.

• Energy Efficiency: Optimizes motor performance through real-time network control.

FAQ

1. Q: What fieldbus protocol does the AFPS-01C support?

   A: The AFPS-01C supports PROFIBUS DP communication protocol.

2. Q: Is the AFPS-01C compatible with the ACS550 drive?

   A: Yes, it is compatible with ABB ACS350, ACS550, and ACS800 series drives.

3. Q: Can the module be installed without shutting down the system?

   A: No, it is not hot-swappable. Power down the drive before installation.

4. Q: How do I configure the PROFIBUS address for AFPS-01C?

   A: Configuration is done via the drive interface or external DIP switches depending on your setup.

5. Q: What does the diagnostic LED indicate?

   A: It provides visual feedback for power, communication status, and fault conditions.

6. Q: What is the IP rating of the module?

   A: The AFPS-01C has an IP20 ingress protection rating.

7. Q: What is the weight of the AFPS-01C module?

   A: The module weighs 1.15 kg.

8. Q: Does this module require external power supply?

   A: No, it is powered directly from the ABB drive’s internal bus.

9. Q: Can this be used in outdoor environments?

   A: No, the module should be installed inside a protected electrical cabinet.

10. Q: Is it possible to update the firmware of the AFPS-01C module?

    A: No, the AFPS-01C does not support firmware upgrades. It comes pre-programmed and relies on the drive firmware and GSD files for network-level integration.
