Bently Nevada 3500/05-01-02-00-00-00 3500/05 System Rack

The Bently Nevada 3500/05-01-02-00-00-00 system rack is a high-performance, modular chassis designed to house and interconnect up to 14 Bently Nevada 3500 Series modules, offering reliable support for machinery condition monitoring and protection applications. This model features rear I/O capability and an updated configuration to accommodate a single power supply, optimizing rack layout for compact installations in industrial control rooms or field enclosures.

The 3500/05 rack is the foundational component of the 3500 system, providing mechanical support, electrical backplane connectivity, grounding integration, and environmental durability. Its standard 19-inch width conforms to widely adopted rack-mount cabinet formats, simplifying system integration. This rack is used globally in applications where continuous and accurate machinery monitoring is critical to plant safety, uptime, and performance.

Technical Specifications

Applications

The 3500/05-01-02-00-00-00 system rack is widely used in advanced machinery diagnostics and protection scenarios across industries:

• Oil and Gas Production

  Deployed in compressor stations, refineries, and offshore platforms to support vibration and position monitoring modules.

• Power Generation

  Integrated with turbine and generator monitoring systems for condition-based maintenance and fault detection.

• Chemical and Petrochemical Plants

  Monitors mechanical integrity of pumps, fans, and blowers in volatile processing environments.

• Mining and Metals

  Used in high-vibration operations to protect rotating assets like crushers and conveyors.

• Pulp and Paper Mills

  Enables continuous health checks for motors and gear systems in 24/7 processing environments.

• Water and Wastewater Facilities

  Facilitates monitoring of flow and lift station equipment to minimize unplanned downtime.

Advantages

• Rear I/O Access

  Improves cable management and serviceability by allowing all wiring from the back of the rack.

• Standard 19-Inch Format

  Compatible with widely used industrial cabinet systems for fast integration.

• Modular Scalability

  Supports a wide range of monitoring and relay modules for fully customized configurations.

• Robust Construction

  Designed to withstand harsh industrial conditions including high temperature and vibration.

• Integrated Grounding

  Built-in system ground plane improves safety and signal integrity.

• Passive Cooling

  Eliminates moving parts and ensures long-term reliability with no maintenance fans required.

• Optimized for Single Power Supply

  Efficient configuration for applications not requiring redundant power.

• Quick Installation

  Tool-less module mounting and backplane auto-connection streamline setup.

Frequently Asked Questions (FAQ)

Q1: How many modules can the rack hold?

A1: The rack holds up to 14 modules, including monitoring, relay, communication, and power supply cards.

Q2: Does this rack have rear I/O access?

A2: Yes, it supports rear I/O for cleaner wiring and easier maintenance.

Q3: Can this rack operate with redundant power supplies?

A3: No, this configuration supports only a single power supply.

Q4: Is this rack compatible with older 3500 modules?

A4: Yes, it supports all standard 3500 Series modules.

Q5: What kind of cooling does the rack use?

A5: The system uses passive cooling and does not require internal fans.

Q6: Can it be used in outdoor environments?

A6: It is intended for control rooms or enclosed panels; outdoor use requires proper environmental enclosures.

Q7: What are the mounting options?

A7: Standard 19-inch rack mounting is supported.

Q8: What is the construction material?

A8: The rack is made of anodized aluminum with stainless steel hardware.

Q9: Is grounding integrated into the rack?

A9: Yes, a built-in grounding rail is included for safety and EMI protection.

Q10: What is the total weight of the rack?

A10: The rack weighs approximately 4.5 kg.
