Yokogawa SDV541 Digital Output Module

The Yokogawa SDV541 Digital Output Module is a highly reliable and efficient module designed for digital output control in industrial automation applications. It is part of Yokogawa’s STARDOM™ and CENTUM™ systems and offers an excellent solution for applications requiring high-precision digital signal output.

This module provides reliable control of various devices and machinery, such as valves, solenoids, and alarms, enabling seamless integration into the larger process control systems. With high-speed digital output capabilities, the SDV541 ensures accurate operation for a wide range of industrial control applications.

The SDV541 module’s compact design and robust performance make it suitable for diverse applications across various industries such as process control, building automation, and energy management. It plays a crucial role in controlling machinery and devices, ensuring optimized performance and reduced downtime in complex control systems.

Product Specifications

Below are the key specifications for the Yokogawa SDV541 Digital Output Module:

Applications of the Product

The Yokogawa SDV541 Digital Output Module is designed to serve a wide variety of industrial automation and control applications. Some of its primary applications include:

• Process Control Systems: The SDV541 is ideal for controlling digital outputs in process automation systems, where it can manage equipment such as motors, pumps, solenoids, and valves to optimize industrial operations.

• Building Automation: In modern buildings, the SDV541 can be used to control systems like lighting, HVAC, and fire alarms. Its reliable output control ensures energy-efficient operations in building management systems.

• Control of Automated Machinery: This module is widely used in industries that rely on automated machinery, such as manufacturing plants and assembly lines. It helps control critical machines, ensuring that production processes run smoothly.

• Energy Management Systems: The SDV541 can be used to control energy-consuming devices, helping optimize energy usage and minimize unnecessary consumption. This feature is particularly valuable in industrial energy management systems.

• Remote Control of Devices: The SDV541 can be deployed in remote control systems, enabling operators to manage various field devices such as valves and actuators in real-time.

• Alarm Systems: The module can interface with alarm and indication systems to trigger digital alarms and indicators in response to changes in system conditions, ensuring real-time monitoring and rapid response.

Advantages of the Product

The Yokogawa SDV541 Digital Output Module offers several key advantages, making it a highly effective component for industrial control systems:

• Compact and Lightweight: With its dimensions of 130 x 107.5 x 32.8 mm and weight of just 0.29 kg, the SDV541 is a compact and lightweight module that fits easily into control panels and other industrial setups where space is limited.

• High-Speed and Reliable Output: The SDV541 offers high-speed digital output with 500 mA per channel, ensuring precise control of connected devices and equipment.

• Wide Operating Temperature Range: The module operates in a wide temperature range, from -10°C to +60°C, allowing it to perform reliably in both extreme and standard environments, such as those found in manufacturing and processing industries.

• DIN Rail Mounting: The SDV541 uses DIN rail mounting, making it easy to install and secure within industrial control cabinets. This mounting type simplifies integration into existing control systems and improves overall system organization.

• Power Efficiency: With a low power consumption of just 3 W, the SDV541 contributes to energy savings in industrial applications, reducing the overall operating costs of the control system.

• Seamless Integration: The IEC 61131-2 compliant interface ensures compatibility with various control systems, simplifying installation and ensuring reliable communication between modules in the control system.

Frequently Asked Questions (FAQ)

1. What is the primary function of the Yokogawa SDV541 Digital Output Module?

   • The SDV541 module provides reliable digital output control for industrial devices, such as solenoids, valves, and alarms, in process automation and other industrial applications.

2. How many digital output channels does the SDV541 module have?

   • The SDV541 module has 8 digital output channels.

3. What is the output voltage of the SDV541 module?

   • The output voltage is 24 V DC.

4. What is the current output per channel for the SDV541 module?

   • The module provides 500 mA per channel.

5. What are the dimensions of the SDV541?

   • The dimensions are 130 x 107.5 x 32.8 mm.

6. What is the weight of the SDV541 module?

   • The SDV541 weighs 0.29 kg.

7. What is the power consumption of the SDV541 module?

   • The module consumes 3 W of power.

8. How is the SDV541 module mounted?

   • The SDV541 is mounted using a DIN rail, which ensures easy installation and secure placement within control panels.

9. What is the operating temperature range of the SDV541 module?

   • The module can operate in temperatures ranging from -10°C to +60°C.

10. Is the SDV541 module compliant with industry standards?

• Yes, the SDV541 is IEC 61131-2 compliant, ensuring compatibility with various industrial control systems and providing reliable performance in diverse applications.
