Honeywell FC-TSAI-1620M Analog Input Module

The Honeywell FC-TSAI-1620M is a high-performance Analog Input Module designed for use in Honeywell’s Safety Manager and Experion PKS systems. This module serves as a critical interface between field analog sensors and the control or safety system, converting real-world physical signals such as temperature, pressure, flow, and level into digital data for processing and monitoring.

Built with industrial-grade reliability, the FC-TSAI-1620M supports multiple analog signal types, including current and voltage inputs. It features advanced diagnostics and redundancy options, ensuring continuous and accurate data acquisition in demanding process environments.

This module’s robust design, combined with Honeywell’s advanced safety certification, makes it ideal for applications requiring both precision and high integrity.

Technical Specifications

Product Applications

The FC-TSAI-1620M Analog Input Module is widely used in industries requiring precise and reliable analog data acquisition, including:

• Oil & Gas Processing – Monitoring pressures, flows, and temperatures in upstream and downstream operations.

• Chemical and Petrochemical Plants – Data acquisition for process control and safety systems.

• Power Generation – Inputs from sensors measuring steam, water levels, and other critical parameters.

• Water and Wastewater Treatment – Accurate monitoring of chemical dosing and water quality parameters.

• Manufacturing Automation – Control systems requiring analog input for various industrial processes.

• Pharmaceuticals and Food Processing – Ensuring process accuracy and compliance with quality standards.

Product Advantages

• High Accuracy and Fast Response: Provides precise analog data with response times under 100 ms.

• Multiple Signal Compatibility: Supports common industrial analog inputs such as 4–20 mA and 0–10 V.

• Built-in Diagnostics: Detects wiring faults, open circuits, and sensor failures to enhance reliability.

• Redundancy Support: Designed for use in safety systems requiring SIL 3 certification.

• Robust Construction: Industrial-grade design suited for harsh environments.

• Easy Integration: Seamlessly integrates into Honeywell Safety Manager and Experion PKS systems.

Frequently Asked Questions (FAQ)

1. What types of analog signals does the FC-TSAI-1620M support?

   It supports 4–20 mA current and 0–10 V voltage input signals.

2. How many input channels are available on this module?

   The module provides 16 analog input channels.

3. What is the accuracy of the analog inputs?

   The accuracy is ±0.1% of full scale.

4. What safety certification does the module have?

   It is TÜV-certified for SIL 3 according to IEC 61508.

5. Can the module detect sensor or wiring faults?

   Yes, it features diagnostics for open circuits, shorts, and sensor failures.

6. What is the module’s operating temperature range?

   0°C to 60°C (32°F to 140°F).

7. Is the FC-TSAI-1620M compatible with Honeywell Safety Manager?

   Yes, it is designed for full compatibility with Safety Manager SC bus.

8. What is the typical response time?

   Less than 100 milliseconds per channel.

9. What are the physical dimensions of the module?

   210 × 70 × 60 mm.

10. How is the module mounted?

    It supports DIN rail or panel mounting.
