GE Fanuc HE693THM884 8-Channel Analog Current/Voltage Output Module

The GE Fanuc HE693THM884 is an 8-channel analog current/voltage output module for Series 90-30 controllers. This module offers a versatile solution for various industrial applications, providing up to eight single-ended output channels that you can configure for either current loop or voltage outputs.

Key Features

• Versatile Output: You can independently configure each output channel for one of the following ranges:
  • 0 to +10 volts (unipolar)
  • -10 to +10 volts (bipolar)
  • 0 to 20 milliamps
  • 4 to 20 milliamps
• High Resolution: Each channel delivers 15 to 16 bits of resolution, depending on the selected range. This ensures precise analog output.
• Fast Update Rate: The module updates all eight channels every 8 milliseconds. This feature enables real-time control and monitoring.
• Configuration Flexibility: You can easily adjust the module’s configuration using the provided software, allowing for customization to specific application requirements.

Technical Specifications

• Number of Channels: 8
• Output Type: Single-ended
• Output Ranges:
  • Voltage: 0 to +10V, -10 to +10V
  • Current: 0 to 20mA, 4 to 20mA
• Resolution: 15 to 16 bits
• Update Rate: 8 milliseconds
• Series: Series 90-30

Applications

The HE693THM884 is well-suited for a wide range of applications, including:

• Process Control: Optimize complex processes with precise analog output.
• Motor Control: Manage motor functions effectively with high-resolution outputs.
• Data Acquisition: Capture accurate data in real-time for analysis.
• Testing and Measurement: Ensure reliability in testing and measurement tasks
