Yokogawa ADV859 Digital Output Module

The Yokogawa ADV859 Digital Output Module is an integral component in automation and control systems, providing precise digital output capabilities for a wide range of industrial applications. Designed to operate seamlessly with Yokogawa’s advanced Distributed Control Systems (DCS), the ADV859 is engineered to offer both reliability and flexibility, ensuring optimal performance in complex industrial environments.

This module is particularly useful in systems where high-speed and high-precision control of external devices such as relays, actuators, and control valves is required. The ADV859 outputs digital signals (on/off) to manage the operation of these devices, making it indispensable for process automation in industries such as chemical, oil & gas, power generation, and manufacturing.

The ADV859 is compact and lightweight, with an efficient design that enables easy integration into existing systems. Its robust construction ensures durability in harsh conditions, while its user-friendly features make it an excellent choice for both new installations and system upgrades.

Product Parameters

Product Applications

The Yokogawa ADV859 Digital Output Module can be utilized across various industries, providing efficient and reliable control for many types of equipment. Some of the key applications include:

1. Process Control Systems: The ADV859 is widely used in process control systems to send digital signals to control valves, actuators, and relays. It ensures accurate control of the processes that are critical to industrial operations such as chemical production and refining.

2. Energy Generation: In power generation plants, the ADV859 helps control digital devices like circuit breakers, switches, and emergency shutdown systems. The fast response time ensures that safety mechanisms are activated promptly, protecting machinery and personnel.

3. Oil & Gas Industry: The module is essential in oil & gas applications, where it controls critical safety systems such as shutdown valves and pumps. Its robust design and fast response make it ideal for use in hazardous environments.

4. Manufacturing Automation: The ADV859 is used in manufacturing plants for controlling assembly lines, robotic arms, and packaging equipment. Its high output capacity and fast response time are key to maintaining the high speeds and accuracy required in automated systems.

5. Water and Wastewater Treatment: In water treatment facilities, the ADV859 is used to manage equipment such as pumps, motors, and control valves. The module ensures that these critical components operate efficiently, maintaining the required flow rates and water quality standards.

6. Building Automation Systems: The ADV859 is also applied in building automation, where it controls systems such as lighting, heating, ventilation, and air conditioning (HVAC). Its integration with DCS systems enables centralized control, optimizing energy use and improving operational efficiency.

Product Advantages

1. High-Speed Response: The ADV859 has a remarkable response time of just 1 millisecond, ensuring fast and efficient control over connected devices.

2. Compact and Lightweight Design: With dimensions of 130 x 127.2 x 32.8 mm and a weight of 0.3 kg, the ADV859 is compact and easy to install, making it an ideal solution for space-constrained installations.

3. Reliability in Harsh Environments: The ADV859 is built to withstand demanding conditions, offering an IP20 protection class, making it resistant to dust and other environmental factors. This ensures long-term performance in industrial settings.

4. Wide Temperature Range: With an operational temperature range of -20°C to +60°C, the ADV859 is suitable for use in both hot and cold environments, offering flexibility across various industries.

5. Seamless Integration: The ADV859 is designed for easy integration with Yokogawa’s DCS systems, offering a hassle-free installation process. The module is fully compatible with existing control systems, minimizing setup time and cost.

6. Flexible Output Capabilities: The 8 output channels, each capable of delivering up to 0.5 A, make the ADV859 suitable for controlling multiple devices simultaneously. This flexibility makes it ideal for complex systems requiring efficient control.

FAQ

Q1: How many output channels does the ADV859 have?

A1: The ADV859 has 8 output channels, which allows it to control multiple devices simultaneously.

Q2: What is the response time of the ADV859?

A2: The response time of the ADV859 is 1 ms, ensuring fast and precise control.

Q3: What is the maximum current per channel?

A3: Each output channel of the ADV859 can handle up to 0.5 A of current.

Q4: What is the output voltage of the ADV859?

A4: The ADV859 provides a 24V DC output voltage, suitable for most industrial control systems.

Q5: Can the ADV859 module be mounted on a DIN rail?

A5: Yes, the ADV859 can be mounted on a DIN rail or surface-mounted, providing flexibility for different installation types.

Q6: What protection class does the ADV859 have?

A6: The ADV859 has an IP20 protection class, providing protection against dust and ensuring its reliability in industrial environments.

Q7: What is the temperature range for the ADV859?

A7: The ADV859 operates within a temperature range of -20°C to +60°C, making it suitable for use in both hot and cold environments.

Q8: What are the main applications of the ADV859?

A8: The ADV859 is used in process control, power generation, oil & gas, manufacturing automation, water treatment, and building management systems.

Q9: Is the ADV859 compatible with other Yokogawa DCS systems?

A9: Yes, the ADV859 is fully compatible with Yokogawa’s DCS systems, ensuring easy integration into existing setups.

Q10: How does the ADV859 enhance process control systems?

A10: The ADV859 provides precise digital output signals to control critical devices such as valves, motors, and relays, ensuring smooth and efficient operation of automated systems.
