Schneider ABE7H16R20 Passive Connection Sub Base

The Schneider ABE7H16R20 Passive Connection Sub Base is a high-performance industrial component designed to facilitate reliable connections for modular power control systems. It acts as a passive base for connecting the terminal blocks in modular electrical systems, ensuring effective integration of various components within an automation or control system. This sub base is built to meet the high demands of industrial automation environments, offering robust durability, secure electrical connections, and ease of integration.

Product Specifications

Product Applications

The Schneider ABE7H16R20 Passive Connection Sub Base is primarily used in:

• Industrial Automation: It provides reliable electrical connections in automation control systems, integrating sensors, controllers, and actuators.

• Control Panels: Used in the assembly of control panels, it ensures safe and efficient wiring and easy maintenance of industrial automation equipment.

• Power Distribution: A key component in managing the electrical distribution in industrial facilities.

• Building Automation: Helps in establishing connection points for electrical equipment in commercial and residential buildings.

• Machine Tools: Provides passive connections for machine tools, ensuring reliable operations in high-demand environments.

Product Advantages

• Reliable Connectivity: The sub base ensures stable and secure electrical connections, minimizing the risk of faults or interruptions.

• Easy Installation: Designed for quick and simple installation on DIN rails, making it ideal for modern control panel designs.

• Durability: Made from robust polyamide material, the ABE7H16R20 is resistant to industrial wear and tear, offering long-lasting performance.

• Space-Saving Design: Compact and efficient design that helps save space in control panels and automation setups.

• Versatile: Compatible with various Schneider Electric terminal blocks and modules, offering flexibility in electrical system configuration.

• Enhanced Safety: With an IP20 rating, it is suitable for environments where dust and dirt are minimal, enhancing safety by preventing accidental electrical contact.

FAQ

1. What is the purpose of the Schneider ABE7H16R20 Passive Connection Sub Base?

   • The ABE7H16R20 is used to provide secure electrical connections for terminal blocks within modular electrical systems in automation and control applications.

2. What is the maximum voltage rating for the ABE7H16R20?

   • The maximum voltage rating is 690V.

3. What is the current rating of the ABE7H16R20 sub base?

   • The ABE7H16R20 has a current rating of 16A.

4. Can the ABE7H16R20 be mounted on a DIN rail?

   • Yes, the sub base is designed for easy mounting on a DIN rail.

5. What is the operating temperature range for this sub base?

   • The operating temperature range is from -20°C to 60°C.

6. Is the ABE7H16R20 compliant with safety standards?

   • Yes, the sub base complies with CE, UL, and RoHS standards for safety and environmental friendliness.

7. What is the IP rating of the ABE7H16R20?

   • The IP rating of the ABE7H16R20 is IP20, meaning it is protected against solid objects larger than 12mm but not against water ingress.

8. What material is the ABE7H16R20 made from?

   • The sub base is made from polyamide (PA), a durable and insulating material.

9. How much does the ABE7H16R20 weigh?

   • The weight of the ABE7H16R20 is 0.3 kg.

10. What are the typical applications for the ABE7H16R20?

• Typical applications include industrial automation, control panels, power distribution, building automation, and machine tools.
