Bently Nevada 1900/65A General Purpose Equipment Monitor
Item Number: 1900/65A
Brand:Bently Nevada
Lead Time: in stock
Description: General Purpose Equipment Monitor
Payment: T/T
Product Description
Bently Nevada 1900/65A General Purpose Equipment Monitor is a standalone, multi-channel condition monitoring and protection device.
It supports simultaneous connection of vibration, displacement, velocity, and temperature sensors.
Each sensor input is provided with an independent raw signal output.
Additionally, by ordering the 1900/01 Communication Upgrade Kit, Modbus gateway functionality can be added to monitors that do not come with this feature.
Functions and features
- Four sensor inputs: Each input is software-configurable to support 2- and 3-wire accelerometers, velocities, or eddy-current displacement sensors.
- Four temperature inputs: Each input supports E-, J-, K-, and T-type thermocouples, as well as 2- or 3-wire RTDs (resistance temperature detectors).
- Software-based configuration: The 1900/65A can create configuration files using a laptop and dedicated configuration software, and download them to the monitor via the built-in Ethernet interface.
- Optional display module: The 1900/65A supports installation of a remotely mountable display/keypad module (up to 75 meters/250 feet) for viewing channel information or making simple configuration changes.
Specification
|
Parameter |
Description |
|
Model |
1900/65A |
|
Direct |
100 to 500 μm (3 to 20 mils) peak-to-peak |
|
Direct Filter |
1.2 Hz 1-pole low-pass |
|
Gap Filter |
0.41 Hz 1-pole low-pass |
|
OK Filter |
2.4 kHz 1-pole low-pass |
|
Speed Variables |
± 0.5 RPM + 0.015% of reading |
|
Maximum Switched Current |
5 A |
|
Maximum Switched Power |
150 VA |
|
Current Source |
3.3 mA ± 5% |
|
Display |
Liquid Crystal Display (LCD) with backlight |
|
Monitor Module Dimensions (L x W x H) |
196.9 mm x 149.4 mm x 74.4 mm (7.75 in x 5.88 in x 2.93 in) |
|
Monitor Module Weight |
0.77 kg (1.70 lb) |
|
Display Module Dimensions (L x W x H) |
196.9 mm x 149.4 mm x 32.8 mm (7.75 in x 5.88 in x 1.29 in) |
|
Display Module Weight |
0.40 kg (0.89 lb) |
