The GE Fanuc IC610MDL125A is an 8-point input module designed for use with GE Fanuc Series One PLCs. It allows the PLC to receive discrete input signals from devices such as limit switches, pushbuttons, and relay contacts. This module is used primarily in industrial automation systems to interface with various input devices, facilitating control processes in manufacturing and process control environments.

Technical Specifications

• Part Number: IC610MDL125A
• Product Type: 8-Point Input Module
• Input Voltage: 115 VAC (97-132 VAC)
• Input Frequency: 47-63 Hz
• Number of Input Points: 8
• Input Impedance: 9.5 kΩ
• Input Current: 10 mA at 9 VDC
• Internal Power Consumption: 10 mA at 9 VDC
• LED Indicators: 8 LEDs to display the status of input circuits (green for active, red for inactive)
• Operating Temperature Range: 0°C to 60°C (32°F to 140°F)
• Protection: IP20
• Weight: 0.57 lbs
