NI PXIE-4142 PXI Source Measure Unit
Manufacturer:NI
Product Number:NI PXIE-4142
Payment Methods:T/T, PayPal, Western Union
Condition:New & In Stock
Warranty:1 Year
Lead Time:1-3 Working Days
Certificate:COO
Courier partners:DHL, UPS, TNT, FedEx and EMS.
Business hours:7*24
Product Description
The NI PXIe-4142 is a high-performance, four-channel source measure unit (SMU) designed for precise electrical measurement and sourcing within a PXIe (PCI eXtensions for Instrumentation Express) system. This SMU is tailored for applications that require high accuracy, flexibility, and speed in both sourcing and measurement. It features four-quadrant operation, allowing for sourcing and sinking of voltage and current, and integrated remote (4-wire) sensing for accurate measurements.
Technical Specifications
| Parameter Name | Parameter Value |
| Product Model | NI PXIe-4142 |
| Manufacturer | National Instruments |
| Product Type | PXI Source Measure Unit |
| SMU Channels | 4 |
| Voltage Range | ±24 V |
| Current Range | ±150 mA |
| Sampling Rate | Up to 600 kS/s |
| Source-Measure Rate | Up to 15 kS/s |
| Voltage Measurement Sensitivity | 200 µV |
| Current Measurement Sensitivity | 100 pA |
| Interface | PXIe x4 (Gen2) |
| Operating Temperature Range | 0 °C to 55 °C |
| Storage Temperature Range | -40 °C to 70 °C |
| Relative Humidity | 10% to 70% noncondensing |
| Dimensions | 0.8 x 5.1 x 8.5 in. (2.0 cm x 13.0 cm x 21.6 cm) |
| Weight | 14.53 oz. (412 g) |
The NI PXIe-4142 offers several key features and advantages that make it a reliable choice for high-speed digital signal handling applications. Its four-channel, four-quadrant SMU design allows for versatile sourcing and measurement capabilities. The module’s high sampling rate of up to 600 kS/s and maximum source-measure rate of 15 kS/s enable fast and precise measurements, crucial for characterizing devices under test (DUT). The NI PXIe-4142 also features integrated remote (4-wire) sensing capabilities, ensuring accurate measurements by compensating for lead resistance.
The NI PXIe-4142 is widely used in various industrial and research applications where precise voltage and current sourcing and measurement are required. In semiconductor testing, it can be used for characterizing high pin-count devices, ensuring reliable operation and safety. In research and development, the SMU facilitates accurate generation and analysis of voltage and current curves, providing valuable data for scientific research and product development. Its compatibility with various digital systems and high-speed data transfer capabilities make it suitable for applications ranging from simple data logging to advanced process control.
Installation and Maintenance
Pre-installation preparation: Before installing the NI PXIe-4142, ensure you have the module, PXI Express chassis, and appropriate cables. Turn off the power and unplug the chassis. Install the module in the chassis and secure it with the provided screws. Connect the necessary cables and ensure all connections are secure. Maintenance recommendations: Regularly inspect the connections for wear or damage. Clean the module using a soft, non-metallic brush to remove dust and ensure the device is completely dry before reusing it. Store the module in a dry place with relative humidity between 10% and 70% noncondensing.
Product Guarantee
The NI PXIe-4142 is backed by a two to three-year warranty from National Instruments, ensuring the quality and reliability of the product. National Instruments also provides comprehensive after-sales service and technical support to assist customers with any issues or inquiries related to the product. This ensures that customers can use the SMU with confidence, knowing that they have access to reliable support and service from a reputable company.
