The Ovation 5X00058G01 HART Analog Input Module is designed for precise measurement and monitoring of analog signals within Ovation distributed control systems. Supporting HART protocol communication, it enables both analog signal acquisition and digital diagnostics, allowing operators to monitor, configure, and maintain field devices effectively.

Key Features

• Supports HART-enabled analog field devices

• High-accuracy analog signal measurement

• Dual functionality: analog signal acquisition and digital diagnostics

• Compatible with Ovation distributed control systems

• Rugged design for industrial use

• Easy integration with existing Ovation modules

• Supports predictive maintenance and device configuration

Technical Specifications

Industry Applications

• Power Generation – turbine, generator, and motor monitoring

• Oil & Gas – process control and field device diagnostics

• Petrochemical & Chemical – analog signal acquisition and HART communication

• Manufacturing – motors, pumps, and process equipment monitoring

• Water & Wastewater – precise process measurement and control

Advantages

• Provides accurate analog measurement and digital device diagnostics

• Supports HART protocol for enhanced device communication

• Rugged design ensures reliability in industrial environments

• Easy integration into Ovation distributed control systems

• Supports predictive maintenance and field device configuration

• Ensures stable and continuous operation of analog measurement channels

Frequently Asked Questions (FAQ)

Q1: How many analog input channels does this module have?

8 channels.

Q2: What is the input signal range?

4–20 mA.

Q3: Does it support HART communication?

Yes, it supports HART protocol over analog signals.

Q4: What is the measurement accuracy?

±0.1% of full scale.

Q5: What is the operating temperature range?

0 °C to +60 °C.

Q6: How is the module mounted?

Rack or panel mountable.

Q7: Is it suitable for industrial environments?

Yes, it is rugged and durable.

Q8: How is it powered?

Via the Ovation system backplane.

Q9: What are the dimensions and weight?

Approx. 180 mm × 120 mm × 40 mm, 0.9 kg.

Q10: Which industries commonly use this module?

Power generation, oil & gas, petrochemical, manufacturing, and water & wastewater.
