The Emerson SE4001S2T2B5 Discrete Input Card with the KJ4006X1-BP1 Terminal Block and KJ3203X1-BK1 Terminal Block Carrier is a high-performance module designed to capture digital input signals in a wide variety of industrial automation applications. This card provides the capability to handle 16 discrete inputs, allowing systems to accurately monitor on/off status from field devices such as switches, sensors, and relays. Integrated with terminal blocks, this system enables quick and reliable wiring, enhancing installation efficiency and reducing maintenance time.

The SE4001S2T2B5 card supports 24V DC voltage, and it is highly compatible with Emerson’s SE4000 series control systems. It is specifically designed for industries requiring precise, real-time monitoring and control, including power generation, chemical processing, manufacturing automation, and oil & gas operations.

The KJ4006X1-BP1 terminal block and the KJ3203X1-BK1 carrier are engineered to provide secure connections to field devices, reducing the risk of wiring errors and ensuring robust signal transmission. This combination makes the system ideal for installations in control panels, where space is limited, and reliability is paramount.

Product Specifications

Product Applications

The Emerson SE4001S2T2B5 with KJ4006X1-BP1 and KJ3203X1-BK1 is ideal for use in various industrial sectors where discrete input monitoring is essential. Typical applications include:

• Power Generation: The card is used for monitoring control switches, relays, and other field devices to ensure smooth operation of power plants.

• Chemical Processing: Provides reliable digital signal monitoring from devices like pumps, valves, and chemical sensors, crucial for ensuring safety and efficiency in chemical manufacturing.

• Manufacturing Automation: The system is used in production lines to detect changes in status from machines, switches, and sensors, ensuring effective process control.

• Oil & Gas: Used for digital input monitoring from equipment like safety relays and control panels, helping to improve system safety and efficiency in oil rigs and refineries.

• Water Treatment: Monitors signals from pumps, valves, and chemical dosing systems, enabling efficient water treatment processes.

• Industrial Automation: This system is widely used to monitor on/off signals from a wide range of industrial devices, providing reliable data for centralized control and monitoring.

Product Advantages

• High Reliability: The SE4001S2T2B5 ensures high reliability in real-time digital signal processing, contributing to the overall dependability of the industrial control system.

• Efficient Wiring: Integrated terminal blocks (KJ4006X1-BP1 and KJ3203X1-BK1) enable simple and secure field wiring, reducing installation time and minimizing wiring errors.

• Compact Design: The system’s compact size (162 x 41.8 x 199.3 mm) makes it a perfect fit for control panels with space constraints while still providing high performance.

• Wide Temperature Range: With an operating temperature range of -10°C to +60°C, the card can perform reliably in various environments, from hot industrial facilities to cold outdoor settings.

• Energy-Efficient: The card’s low power consumption (4W) ensures that the overall energy usage of the control system remains minimal.

• Easy Integration: Seamless integration into Emerson’s SE4000 control systems allows for flexibility and scalability in control applications.

• Secure and Robust Terminals: The terminal block system (KJ4006X1-BP1) ensures reliable electrical connections, reducing downtime due to wiring issues.
