The ABB CP665 (1SAP565100R0001) is a powerful and versatile Human-Machine Interface (HMI) panel designed to offer intuitive control, real-time monitoring, and efficient interaction between operators and automation systems. It belongs to the CP600 series, ABB’s flagship family of advanced HMI devices, engineered for high-performance visualization in industrial environments.

With a 13.3 inches SVGA touchscreen, robust construction, and wide connectivity options, the CP665 is ideal for deployment in complex automation settings. Whether used in factory floors, machinery dashboards, or process control cabinets, the panel ensures high visual clarity, durability, and seamless integration with PLCs and other control systems.

Its resistive touchscreen, compatibility with ABB’s Panel Builder 600 software, and support for multiple communication protocols make it an adaptable and future-ready solution for industrial automation challenges.

Product Specifications

Applications

The ABB CP665 is designed for a broad spectrum of industrial applications where real-time interaction with automation systems is required. Common use cases include:

• Manufacturing Automation

  Visualizing machine states, alarms, and production metrics on assembly lines or robotic systems.

• Process Control in Oil & Gas

  Used as an HMI panel for compressors, separators, and other processing units in control rooms or hazardous locations (non-classified).

• Power Generation and Distribution

  Monitoring turbines, breakers, and substation equipment with instant access to system diagnostics.

• Water & Wastewater Plants

  Controlling pumps, filtration, chemical dosing, and monitoring tank levels or pressure indicators.

• Packaging and Printing Machinery

  Used to configure operational sequences, monitor print runs, and adjust packaging speeds.

• Food and Beverage Automation

  Ensures process consistency through recipe management, temperature control, and equipment interfacing.

Product Advantages

• Large, Clear Display

  The 12.1” SVGA screen offers high visibility even in low-light factory environments.

• Versatile Communication Interfaces

  Equipped with multiple Ethernet and serial ports for flexible system integration.

• Robust Design

  IP66-rated front panel protects against dust, oil, and water jets, making it suitable for harsh environments.

• Multi-Protocol Compatibility

  Seamlessly communicates with ABB and third-party PLCs via Modbus, OPC UA, Ethernet/IP, and more.

• User-Friendly Engineering Tool

  Integrated with Panel Builder 600 for graphical HMI development and intuitive configuration.

• Future-Ready Architecture

  Designed to handle increasing complexity in automation with ample RAM and flash memory.

• Secure Operation

  Supports password protection, data logging, and secure communication options.

• Long-Term ABB Support

  Backed by ABB’s global service network and consistent firmware/software updates.

• Compact Form Factor

  Slim depth and standard panel cut-out allow for easy retrofitting and new installations.

• Sustainable and Energy-Efficient

  Low power consumption contributes to energy savings and reduced operational costs.

Frequently Asked Questions (FAQ)

1. What software is used to configure the CP665 HMI panel?

   The CP665 is programmed using ABB’s Panel Builder 600, a powerful tool for graphical interface creation and system configuration.

2. Can I connect the CP665 to non-ABB PLCs?

   Yes, it supports open protocols like Modbus, OPC UA, and Ethernet/IP for integration with most major PLC brands.

3. Does the CP665 support remote diagnostics?

   Yes, with Ethernet connectivity and supported protocols, remote monitoring and diagnostics are possible.

4. Is the touchscreen usable with gloves?

   Yes, it features a resistive touchscreen, which works well with gloves or styluses.

5. What is the lifespan of the CP665’s display?

   The LED backlight typically lasts 50,000 hours, depending on brightness settings and environment.

6. Is it possible to upgrade the firmware?

   Yes, firmware updates can be installed via USB or Ethernet using ABB tools.

7. What happens if the power supply fluctuates?

   The CP665 tolerates 18–30 VDC input range, and transient protection is built-in.

8. Does the CP665 have a built-in alarm system?

   Yes, alarms can be configured within the HMI application through Panel Builder 600.

9. How many screens or pages can be programmed?

   The number of screens is limited only by available memory and performance requirements.

10. Can it be used in outdoor installations?

    It is primarily intended for indoor use or protected enclosures; for outdoor use, proper panel housing is required.
