ABB 5SHY4045L0004 Product Introduction

ABB 5SHY4045L0004 is a high-performance semiconductor module with a wide range of applications and multiple functional characteristics.The following is a detailed introduction to this module.

Basic characteristics

Rated voltage and current:The rated voltage is 380V~400V,the rated current is 45A,and the short-time withstand current can reach 1.5kA.

Chipset:Adopts SPT(Soft Pass through)chipset,including SPT+and SPT++versions,which has a larger chip area and can provide higher output power.In particular,its 1700V SPT++chipset,as the world’s first 1700V chipset,can operate at a junction temperature of up to 175°C,helping to improve the design of power-density IGBT modules.

Dimensions and weight:Dimensions are 450x250x300mm and weight is 15kg.

Application fields

Industrial power conversion and drives:including traction,wind turbine converters or other renewable energy sources,industrial drives,etc.

Power Systems:Electronics for FACTS(Flexible AC Transmission Systems)applications.

Solar,battery power converters:also applicable to these renewable energy fields.

Backup system(UPS):Provides uninterrupted power supply to critical equipment.

Functional characteristics

Inverter function:As a thyristor module inverter,its main function is frequency conversion and energy saving.In applications such as fans and water pumps,variable frequency speed regulation can achieve significant power saving effects,with a power saving rate of 20%~60%.In addition,it also has complete detection and protection links to ensure the stable operation of the equipment.

Automation system application:Built-in 32-bit or 16-bit microprocessor,with a variety of arithmetic logic operations and intelligent control functions,the output frequency accuracy is as high as 0.1%~0.01%.This makes it widely used in automation systems,such as the chemical fiber industry,glass industry,electric arc furnace automatic feeding,batching system and intelligent control of elevators.

PLC(Programmable Logic Controller)functions:Mainly used in switch logic control,process control,motion control,data processing,communication and networking.It can replace traditional relay circuits to realize logic control and sequential control.It can be used to control a single device,as well as group control of multiple machines and automated assembly lines.

Medium and high voltage inverter controllable IGCT module:Optimized for low conduction losses,with a typical on/off switching frequency of 500 Hz.Mainly used in DCS systems,robot systems and large servo control systems,etc.

Other Features

Protection function:It has multiple protection functions such as overload,short circuit,undervoltage,etc.

Mechanical life:Mechanical life is up to 1,000,000 times.

Scalability:Simple scalability via EtherCAT(FSoE)with 30 fail-safe inputs or outputs.

Programming and monitoring:In combination with the graphical programming tool,project planning of safety sensors and actuators as well as entire systems can be carried out easily.Safety logic can be implemented and,in combination with encoder boxes,axis-related and spatial movements can be safely monitored.
