The Schneider TSXSAZ10 is an AS-Interface (AS-i) Master Module designed for use with Modicon TSX Micro PLCs. It serves as the communication interface between the PLC and field devices using the AS-i protocol. Compact and DIN-rail mountable, the TSXSAZ10 enables fast, decentralized I/O communication with up to 31 AS-i slaves. It supports direct device addressing and simplifies field wiring for distributed automation systems.

Technical Specifications

Applications

• Decentralized automation in factory and process industries

• Conveyor systems in logistics and warehousing

• Packaging lines and machinery automation

• Material handling and sorting equipment

• Distributed I/O control in automotive production lines

Advantages

• Simplifies wiring with a 2-wire AS-i communication line

• Reduces commissioning time with auto-addressing features

• Enhances reliability through built-in diagnostics

• Compact form factor suitable for confined control panels

• Supports cost-effective expansion of I/O modules

• Compatible with standard Modicon TSX Micro controllers

FAQ (Frequently Asked Questions)

Q1: What is the main function of the TSXSAZ10 module?

A1: It acts as an AS-i master, enabling communication between Modicon TSX Micro PLCs and field I/O devices.

Q2: How many AS-i slave devices can it manage?

A2: It supports up to 31 standard AS-i slave devices.

Q3: Is it compatible with other Modicon PLC series?

A3: It is specifically designed for use with Modicon TSX Micro PLCs.

Q4: Does the module provide diagnostic indicators?

A4: Yes, it has integrated LED indicators for status and diagnostics.

Q5: What is the power supply requirement?

A5: The module operates on a 24 V DC power supply.

Q6: Can it be mounted on a DIN rail?

A6: Yes, it is DIN rail mountable for easy installation.

Q7: What is the communication interface used?

A7: It uses a 2-wire AS-i interface for communication with field devices.

Q8: Is the module hot-swappable?

A8: No, the module should be powered down before replacement.

Q9: What type of environments is it suitable for?

A9: It is suited for industrial environments with an operating range of 0°C to 60°C.

Q10: Can I use it for safety applications?

A10: No, this module is not designed for safety-critical AS-i Safety at Work applications.
