The GE IC693CMM321-EF is an Ethernet Interface Module designed for the GE Fanuc Series 90-30 Programmable Logic Controller (PLC) systems. This module enables the PLC to connect to an Ethernet Local Area Network (LAN) through an external transceiver and an Attachment Unit Interface (AAUI) cable, facilitating seamless communication with hosts and other control devices on the network. By integrating this module, users can enhance the networking capabilities of their PLC systems, allowing for efficient data exchange and remote monitoring.

The IC693CMM321-EF supports both client and server functionalities, providing flexibility in various industrial applications. It features two serial ports: the Station Manager port and the Firmware Upgrade port, along with four LED indicators—OK, LAN, SER, and STAT—that provide status information about the module’s operation.

Product Specifications

Below are the detailed specifications for the GE IC693CMM321-EF Ethernet Interface Module:

Product Applications

The GE IC693CMM321-EF Ethernet Interface Module is utilized in various industrial applications, including:

1. Industrial Automation: Facilitates communication between PLCs and other devices over Ethernet, enabling coordinated control in manufacturing processes.

2. Remote Monitoring and Control: Allows operators to monitor and control PLC operations remotely, enhancing flexibility and responsiveness.

3. Data Acquisition: Enables the collection of data from multiple PLCs over the network for analysis and decision-making.

4. Process Control Systems: Integrates with SCADA systems to provide real-time data exchange and control capabilities.

5. Building Management Systems: Connects PLCs to central management systems for efficient control of building operations.

Product Advantages

1. Enhanced Connectivity: Provides reliable Ethernet connectivity, expanding the communication capabilities of the Series 90-30 PLC.

2. Dual Serial Ports: Offers flexibility with Station Manager and Firmware Upgrade ports for various communication needs.

3. Status Indicators: Four LED indicators provide immediate visual feedback on module status and network activity.

4. Client and Server Capabilities: Supports both client and server functions, allowing versatile network configurations.

5. Standard Compliance: Meets industry standards such as CE and UL, ensuring safety and reliability.

6. Ease of Integration: Designed to fit seamlessly into existing Series 90-30 PLC systems without extensive modifications.

7. Remote Accessibility: Enables remote programming and diagnostics, reducing the need for on-site interventions.

8. Robust Design: Built to withstand industrial environments with a wide operating temperature range and high humidity tolerance.

Frequently Asked Questions (FAQ)

1. What is the primary function of the IC693CMM321-EF module?

   • The module provides Ethernet connectivity for the GE Fanuc Series 90-30 PLC, enabling communication with other devices and systems over a network.

2. How does the module connect to the Ethernet network?

   • It connects via an external transceiver using a 14-pin AAUI port and cable.

3. What are the power requirements for the IC693CMM321-EF?

   • The module consumes 700mA at +5V DC, plus any additional power required by the optional AAUI transceiver.

4. Can this module be used for remote programming of the PLC?

   • Yes, it supports remote programming and diagnostics over the Ethernet network.

5. What types of devices can communicate with the PLC through this module?

   • Any networked devices that support compatible Ethernet communication protocols can interact with the PLC via this module.

6. Are there any LED indicators on the module?

   • Yes, it has four LEDs: OK, LAN, SER, and STAT, which indicate the module’s operational status and network activity.

7. Is the IC693CMM321-EF compatible with all Series 90-30 PLCs?

   • It is designed for compatibility with Series 90-30 PLCs, but it’s advisable to check specific CPU version requirements.

8. What is the operating temperature range for this module?

   • The module operates within a temperature range of 0°C to 60°C.

9. Does the module support both client and server functionalities?

   • Yes, it supports both client and server capabilities for versatile network configurations.

10. What compliance certifications does the IC693CMM321-EF have?

    • The module complies with CE and UL standards, ensuring adherence to safety and performance regulations.
