The Bently Nevada 149776-01 Trendmaster Ethernet Comm Card is an essential communication interface module designed for the Bently Nevada 3500 machinery protection system. This card provides a robust and reliable Ethernet communication link between the 3500 rack and external monitoring or control systems, ensuring fast and secure data transfer for real-time machinery diagnostics and plant asset management.

Engineered for industrial environments, the 149776-01 card supports high-speed communication protocols and integrates seamlessly with plant networks. It allows operators and engineers to remotely access vibration data, system status, alarm events, and configuration details without needing physical access to the rack. This reduces downtime, simplifies maintenance, and enhances the effectiveness of condition monitoring programs.

With advanced features such as Modbus TCP/IP support and compatibility with System 1 software, this communication card is a cornerstone for digital integration in predictive maintenance and reliability-centered maintenance (RCM) strategies.

Product Parameters

Product Applications

• 3500 System Communication – Acts as the primary communication interface for transmitting machinery health and protection data.

• Plant Asset Management – Facilitates integration with software platforms such as Bently Nevada System 1.

• Remote Monitoring – Enables engineers to access vibration, position, and system health data over Ethernet networks.

• SCADA & DCS Integration – Provides Modbus TCP/IP support for seamless integration with plant-wide control systems.

• Redundant Architectures – Can be paired with a second Ethernet card to provide fault-tolerant communication.

• Industrial Plants – Widely used in oil & gas, power generation, marine, and chemical industries where continuous machinery monitoring is critical.

Product Advantages

1. High-Speed Communication – Ensures fast and reliable data transfer through 10/100 Mbps Ethernet.

2. Seamless Integration – Compatible with SCADA, DCS, and asset management software.

3. Remote Accessibility – Provides full visibility of the 3500 rack without physical access.

4. Enhanced Redundancy – Supports dual-card redundancy for uninterrupted communication.

5. Secure Protocols – Designed with industry-standard communication protocols to ensure compatibility and reliability.

6. Improved Plant Efficiency – Enables predictive maintenance strategies by providing real-time vibration and machinery condition data.

7. Flexible Networking – Supports both static IP addressing and DHCP for simplified setup.

8. Industrial-Grade Reliability – Built to withstand harsh industrial environments with extended temperature and humidity tolerance.

9. Reduced Downtime – Allows quicker troubleshooting and monitoring without requiring direct system intervention.

10. Field Proven – Trusted in thousands of industrial installations worldwide for critical machinery monitoring.

FAQ

1. Which systems are compatible with the 149776-01 Ethernet Communication Card?

   It is specifically designed for the Bently Nevada 3500 Machinery Protection System.

2. What communication protocols does this card support?

   The card supports Modbus TCP/IP and proprietary Ethernet protocols for System 1 connectivity.

3. Can this card be configured with dynamic IP addressing?

   Yes, it supports both static IP configuration and DHCP.

4. Does it allow redundant communication setups?

   Yes, two Ethernet Communication Cards can be installed for redundant operation.

5. What is the maximum supported Ethernet speed?

   The card supports 10/100 Mbps with auto-sensing capability.

6. How does this card integrate with System 1 software?

   It provides direct Ethernet connectivity, transmitting vibration and condition monitoring data to System 1.

7. Is the card hot-swappable within the 3500 rack?

   No, it requires system power-down during installation or replacement.

8. What environmental limits does the card support?

   It operates between 0°C to +65°C and can be stored between -40°C to +85°C, with 95% non-condensing humidity.

9. Does this card require additional external power?

   No, it receives power directly from the 3500 rack backplane.

10. Can the Ethernet Communication Card be used for both monitoring and configuration?

    Yes, it allows remote access to both system monitoring data and configuration functions.
