Emerson VE4001S4T1B2 Discrete Input Card

The Emerson VE4001S4T1B2 is a Discrete Input Card designed to provide high-performance, reliable input capabilities for automation and control systems. This card supports 16 discrete channels of input, making it an ideal solution for applications requiring a small footprint and efficient signal processing. Designed specifically for use with Emerson’s Series 4 systems, this input card enables seamless integration into existing control infrastructures, allowing for the monitoring and management of discrete devices such as sensors, limit switches, and relays.

The VE4001S4T1B2 operates at 24V DC, a widely used standard in industrial control systems. The card is compact, yet powerful, ensuring maximum space utilization and reliable data transmission for discrete inputs in automation systems. Its integration flexibility makes it well-suited for industrial automation, manufacturing, and process control environments.

Product Parameters

Product Applications

The VE4001S4T1B2 Discrete Input Card can be employed in various industrial and manufacturing sectors where real-time control and data acquisition are necessary. Some key applications include:

• Industrial Automation: Used to interface with a wide range of field devices such as limit switches and position sensors, ensuring the smooth operation of automated systems.

• Manufacturing Lines: Supports automated assembly lines and conveyor systems by collecting data from numerous discrete devices, such as sensors and actuators.

• Process Control: Provides input for control systems that manage the flow of materials, chemicals, or other resources in process industries.

• Energy Management: Helps monitor operational parameters in energy generation and distribution systems, ensuring efficient management of resources.

• Building Automation: Can be used in HVAC (Heating, Ventilation, and Air Conditioning) and other building control systems to manage environmental conditions.

• Safety Systems: Used in safety-critical systems for real-time monitoring of switches and relays to ensure safety and reliability.

Product Advantages

• Compact and Space-Saving: With dimensions of 107 x 41 x 105 mm, the VE4001S4T1B2 is compact, helping maximize space in control cabinets and systems with limited space.

• High Channel Density: Supports 16 discrete channels, enabling efficient data collection from multiple devices in industrial control systems.

• Seamless Integration: Designed to work with Emerson Series 4 systems, this card integrates seamlessly into existing automation frameworks, reducing configuration complexity.

• Easy Installation: Featuring screw terminal connections, it simplifies installation and reduces potential errors during setup.

• Reliable Performance: The card offers 24 V DC operation, delivering stable performance even in demanding industrial environments.

• IP20 Protection: The IP20 rating ensures the card is protected from dust, making it suitable for indoor applications in controlled environments.

• Cost-Effective: Designed to offer a cost-effective solution for high-density signal input requirements, the VE4001S4T1B2 is an affordable choice for industrial applications.

FAQ

1. What is the number of channels supported by the VE4001S4T1B2?

   • The VE4001S4T1B2 supports 16 discrete input channels.

2. What type of signal does the card handle?

   • The VE4001S4T1B2 handles discrete input (DI) signals, typically from field devices such as switches and relays.

3. What voltage does this card operate on?

   • The card operates at 24 V DC, which is standard for most industrial control systems.

4. What is the current rating for each channel on the card?

   • Each channel on the VE4001S4T1B2 supports a current rating between 5-30 mA.

5. Is the card compatible with other Emerson systems?

   • The card is designed for use with Emerson Series 4 systems, but it may also be compatible with other Emerson control systems that support 24 V DC inputs.

6. What type of connectors are used for installation?

   • The card uses screw terminal connectors, ensuring reliable and easy wiring for field devices.

7. What is the environmental protection rating for this card?

   • The VE4001S4T1B2 has an IP20 rating, offering protection from dust ingress in indoor environments.

8. What are the primary industries that use this product?

   • The VE4001S4T1B2 is used in industrial automation, manufacturing, process control, energy management, and building automation systems.

9. Can this card be used in outdoor or harsh environments?

   • The card has an IP20 rating, which means it is not suitable for outdoor use or in environments with high moisture levels or extreme dust exposure.

10. How does this card integrate with automation systems?

• The VE4001S4T1B2 integrates seamlessly with Emerson Series 4 systems, allowing for real-time monitoring and control of discrete devices such as sensors, relays, and switches.
