Bently Nevada 3500/33 184631-01 + 149986-01 16-Channel Relay Module

The Bently Nevada 3500/33 184631-01 + 149986-01 is a 16-channel relay module designed for use in industrial systems that require reliable monitoring and control. It is part of the Bently Nevada 3500 series, which is known for its comprehensive monitoring capabilities for industrial machinery. This module is ideal for systems where quick relay output responses are required, such as emergency shutdowns, alarms, and system control in power plants, oil refineries, and manufacturing facilities.

The module supports 16 relay channels, offering both flexibility and reliability in managing large systems. It enables seamless integration into industrial automation systems, providing direct control of external devices like actuators, valves, and alarms. With its robust design and operational versatility, the 3500/33 module enhances machinery safety and performance by offering precise, real-time control over connected devices.

Product Specifications

Product Applications

The 3500/33 184631-01 + 149986-01 module is a versatile solution that finds applications across several industries, including:

1. Industrial Control Systems

   This relay module is used extensively in automation systems where multiple relay channels are required to control external devices like motors, actuators, and alarms.

2. Machine Protection

   The module plays a key role in machine protection, enabling the activation of shutdown or alarm systems to prevent equipment failure and protect machinery from damage.

3. Oil & Gas Industry

   In the oil and gas sector, the 3500/33 module is crucial for maintaining the safety and reliability of machinery operating in challenging, remote environments.

4. Power Plants

   The relay module is designed for use in power generation plants, ensuring that critical equipment remains functional and safe through constant monitoring and control.

5. Emergency Shutdown Systems

   The module triggers emergency shutdowns and alarms, acting as a fail-safe mechanism to protect sensitive industrial equipment from potential damage.

6. Alarm and Safety Systems

   The 3500/33 is used in industrial alarm and safety systems to quickly activate external alarms or take necessary safety actions in response to detected failures or anomalies.

Product Advantages

1. High Relay Density

   The 3500/33 184631-01 + 149986-01 offers 16 independent relay channels, enabling simultaneous control of multiple devices without compromising space or efficiency.

2. Rapid Response Time

   The module provides a relay switching time of less than 10 ms, ensuring fast and effective response to changes in the system, which is essential in protecting critical equipment.

3. Wide Temperature Range

   With an operational temperature range of -40°C to +70°C, the module is capable of functioning in extremely harsh environments, making it suitable for use in remote industrial locations.

4. Independent Channel Operation

   Each of the 16 channels operates independently, providing flexibility in controlling different devices without interference between channels.

5. Electrical Isolation Between Channels

   The module ensures 250V AC isolation between channels, providing a high level of protection against electrical faults that could affect other devices in the system.

6. LED Status Indicators

   Each channel has an LED status indicator, allowing operators to easily monitor the operation of each relay and quickly identify any issues or failures.

7. Compact Design

   Despite offering 16 channels, the module has a compact form factor that makes it easy to integrate into existing control panels without requiring excessive space.

8. Simple Integration

   The 3500/33 module can be easily integrated into industrial control systems and is compatible with both DIN rail and panel mounting for flexible installation options.

9. Durable and Reliable

   Designed with industrial-grade components, the module is built for longevity and offers minimal maintenance, even under demanding operating conditions.

10. IP20 Protection

    With an IP20 protection rating, the module is resistant to dust and is suitable for use in indoor environments, ensuring reliable performance over time.

FAQ

Q1: How many relay output channels are there in the 3500/33 module?

A1: The 3500/33 184631-01 + 149986-01 features 16 independent relay output channels.

Q2: What is the switching time for the relays in the module?

A2: The switching time for the relays is less than 10 milliseconds.

Q3: What is the weight of the 3500/33 module?

A3: The module weighs 0.7 kg.

Q4: What is the power supply requirement for this relay module?

A4: The 3500/33 requires a 24V DC ±10% power supply.

Q5: Can this module be mounted on a DIN rail?

A5: Yes, the 3500/33 can be mounted on both DIN rail and panel mounts.

Q6: What is the temperature range in which this module operates?

A6: The module operates in temperatures ranging from -40°C to +70°C, making it suitable for harsh industrial environments.

Q7: Does this module provide electrical isolation between the relay channels?

A7: Yes, there is 250V AC isolation between the relay channels for safe operation.

Q8: How can I monitor the status of the relays?

A8: Each relay channel has an LED indicator that displays the status of the channel, making it easy for operators to monitor performance.

Q9: Is the module suitable for use in power generation plants?

A9: Yes, the 3500/33 is specifically designed for use in power generation plants for critical equipment monitoring and control.

Q10: What environmental protection rating does the module have?

A10: The 3500/33 has an IP20 protection rating, which ensures protection from dust and makes it suitable for indoor use.
