Honeywell CC-TDOR11 Digital Output Modules

Honeywell CC-TDOR11 is a high-performance digital output module designed for use in Honeywell’s Experion Process Knowledge System (PKS). This module enables direct interfacing between the control system and field devices such as actuators, solenoids, or relays. Known for its robustness, precise control, and seamless integration, it supports critical industrial applications with reliability and efficiency.

The CC-TDOR11 is part of Honeywell’s ControlEdge and C300 system family and plays a key role in process automation environments that demand consistent and safe digital output control. It operates with multiple channel configurations and supports diagnostic features for enhanced system monitoring.

Product Features and Advantages

• High Output Reliability: Ensures accurate switching with galvanic isolation, minimizing interference from external noise.

• Multiple Channel Output: Supports multiple digital output channels for wide device control capability.

• Integrated Diagnostics: Offers advanced diagnostics including open circuit, short circuit, and field power loss detection.

• Hot Swappable: Allows for module replacement without shutting down the entire system, reducing downtime.

• Compact and Modular: Designed to fit seamlessly into existing system chassis while saving space.

• Long Lifecycle Support: Backed by Honeywell’s industrial-grade support and long-term availability roadmap.

• Secure Communications: Includes cybersecurity features that meet industry standards for secure operations.

Technical Specifications

Applications

• Oil & Gas: Controls digital actuators and valves in refinery and offshore environments.

• Power Generation: Interfaces with electrical output devices in turbine control systems.

• Pharmaceuticals: Operates digital drives and feedback devices in GMP-compliant environments.

• Chemical Processing: Ensures precise control of pumps, motors, and alarms.

• Food and Beverage: Coordinates discrete devices in packaging and bottling lines.

• Water & Wastewater: Enables control over motor starters and solenoids in SCADA systems.

Product Advantages

• Enhanced Safety: Built-in diagnostic alerts reduce the risk of unnoticed failures.

• Flexible Integration: Works seamlessly with a wide range of Honeywell controllers and third-party interfaces.

• Scalable Architecture: Easily adaptable to both small and large-scale control systems.

• Fast Response Time: Supports real-time control for time-critical operations.

• Reduced Maintenance: Durable design and error reporting lower the total cost of ownership.

• Energy Efficiency: Consumes low power and reduces load on the control system.

FAQs

Q1: What does the CC-TDOR11 module do?

A1: It provides 16-channel digital output control to operate actuators and devices in industrial control systems.

Q2: Can I replace the CC-TDOR11 module without shutting down the system?

A2: Yes, it supports hot-swapping, which allows you to replace it during live operation.

Q3: Is the CC-TDOR11 compatible with non-Honeywell systems?

A3: It is optimized for Honeywell systems like C300 but can interface with other systems using standard protocols.

Q4: What protection mechanisms are in place?

A4: Each channel is protected against short circuits and overcurrent conditions.

Q5: How many devices can the module control at once?

A5: It supports 16 outputs, each capable of driving an individual device.

Q6: What kind of diagnostics are included?

A6: It includes open load detection, short circuit detection, and output status monitoring.

Q7: What type of signals does the module output?

A7: The module provides 24 VDC sinking digital outputs.

Q8: Does it support redundant configurations?

A8: Yes, it can be configured as part of a redundant setup for enhanced reliability.

Q9: Is additional software required for configuration?

A9: Configuration is typically handled through Honeywell’s Control Builder or Experion software suite.

Q10: What is the typical lifespan of the CC-TDOR11 module?

A10: Designed for industrial use, it typically lasts 10+ years under normal operating conditions.
