Schneider ABE7R16T111 Sub-Base With Plug-In Electromechanical Relay

The Schneider Electric ABE7R16T111 is a high-performance relay sub-base module designed for use in modular industrial control systems. Part of the Telemecanique Sensors ABE7 range, this model supports 16 channels and is equipped to host plug-in electromechanical relays, offering an efficient and field-serviceable solution for automation and control.

Designed to interface between the control logic (such as a PLC or remote I/O) and field devices, the ABE7R16T111 allows operators to handle switching loads reliably through a centralized relay base. With its screw terminal connections and DIN rail mounting, this model is particularly favored in environments where ease of wiring, fast relay replacement, and robust electrical performance are required.

Ideal for complex and high-density control panels, the ABE7R16T111 significantly reduces wiring clutter, minimizes downtime, and ensures long-term reliability in harsh industrial environments.

Product Specifications

Product Applications

The Schneider ABE7R16T111 is engineered to serve as a versatile I/O relay interface in a wide range of industrial control applications:

• PLC Output Extension: Acts as an intermediary relay output module between a PLC and actuators.

• Machine Automation: Facilitates signal routing for motors, valves, solenoids, and sensors.

• Process Control Systems: Used in distributed systems for batch and continuous processes.

• Building Automation: Supports lighting, HVAC, and safety relay interfacing.

• Material Handling Equipment: Controls conveyors, packaging machines, and robotic arms.

• Energy Management and Monitoring: Integrates with power meters and smart panels.

Product Advantages

• Modular and Serviceable Design: Plug-in relay slots enable fast replacement without rewiring.

• Durability in Harsh Conditions: Engineered to handle industrial-grade shock, vibration, and thermal variations.

• Simplified Installation: Standard DIN rail mount and clear terminal labeling reduce setup time.

• Time-Saving Maintenance: No need to remove wires when servicing relays.

• High Channel Density: Supports 16 channels in one compact module, ideal for space-constrained panels.

• Reliable Connections: Screw terminals provide secure and vibration-resistant wiring.

• Standards-Compliant: Meets global safety and quality certifications.

• Expandable Architecture: Compatible with Schneider’s full ABE7 interface system for scalable projects.

Frequently Asked Questions (FAQ)

1. Q: What relay series is compatible with the ABE7R16T111?

   A: It is designed for RXM plug-in miniature relays from Schneider Electric.

2. Q: Does the product come with relays pre-installed?

   A: No, relays are ordered separately and plugged into the base during installation.

3. Q: Can it be mounted in any orientation?

   A: It should be mounted vertically on a 35 mm DIN rail to ensure optimal cooling and function.

4. Q: What is the difference between ABE7R16T111 and ABE7R16S111?

   A: The “T” version uses plug-in relays with screw terminals; the “S” version has soldered relay connections.

5. Q: Is it suitable for 230V AC loads?

   A: The sub-base itself operates at 24V DC; however, the relay contacts may switch higher voltages depending on the relay used.

6. Q: Can relays be replaced without removing wires?

   A: Yes, the plug-in design allows relay replacement without disturbing terminal wiring.

7. Q: Is it RoHS and CE certified?

   A: Yes, it complies with RoHS directives and CE marking.

8. Q: What protection is provided against vibration?

   A: It meets industrial vibration standards up to 2g (10–150 Hz).

9. Q: What kind of screw terminals are used?

   A: It uses cage clamp screw terminals for secure and easy wiring.

10. Q: Is this product UL certified for North American use?

    A: Yes, it has UL and CSA certifications for use in North America.
