MTL 3052 Digital Isolator

The MTL3052 is a single-channel, fully floating digital isolator manufactured by MTL Instruments. It provides electrical isolation between input and output circuits, enhancing safety and reliability, especially in hazardous area applications.

Key Features

• Hazardous Area Compatibility: The MTL3052 suits Zone 0, IIC, T4-6, and Div 1, Group A hazardous locations.
• Signal Isolation: It isolates input and output circuits effectively, preventing electrical interference and ground loops.
• Wide Signal Bandwidth: The MTL3052 handles signals up to 10 kHz, ensuring efficient data transmission.
• No-Fail Earth Fault Protection (Optional): The optional no-fail earth fault protection enhances safety further.
• Robust Design: The MTL3052 withstands harsh industrial environments, ensuring long-term durability.

Technical Specifications

• Number of Channels: 1
• Signal Bandwidth: DC to 10 kHz
• Minimum Output Voltage: Dependent on input voltage and current (refer to the datasheet for details)
• Input and Output Circuit Ripple: Less than 1 mA peak-to-peak
• Power Dissipation: Maximum of 160 mW at 12V with a 20 mA signal
• Fuse: Replaceable 50 mA fuse
• FM Max Entity Parameters: Voc = 15V, Isc = 83.3 mA, Ca = 0.75 µF, La = 5.2 mH

Benefits

• Improved Safety: The MTL3052 protects personnel and equipment from electrical hazards.
• Enhanced Reliability: It ensures data integrity and maximizes system uptime.
• Reduced Maintenance: Its robust design minimizes downtime and maintenance needs.
• Versatile Application: The MTL3052 is suitable for various industrial applications.
• Cost-Effective: It provides a reliable and affordable solution for hazardous area installations.
