General Electric IS220PCLAH1B Core Analog I/O Module
Item Number: IS220PCLAH1B
Brand: GE
Lead Time: In stock
Description:Core Analog I/O Module
Payment: T/T
Product Description
GE IS220PCLAH1B is a core analog I/O module in the Mark Vie series, primarily designed for aero-derivative gas turbines and related control applications. The IS220PCLAH1B provides a variety of analog input/output (I/O) functions, supporting thermocouples, RTDs, and other signal types.
Note: The IS220PCLAH1B can be used with the SCLS/SCLT terminal block to expand I/O channels (for example, the SCLT supports fan signals from one to three PCLA modules).
Function & Features
- Terminal Board Compatibility: The GE IS220PCLAH1B must be used with either the SCLS (signal conditioning) or SCLT (terminal extension).
- The GE IS220PCLAH1B supports various control architectures: dual controllers + TMR I/O (triple redundancy), dual controllers + simplex I/O, and single controller + TMR I/O.
- Terminal Connections: The SCLS terminal board uses 48/72-pin Euro-style terminals for connecting to field devices. The SCLT terminal board connects to the SCLS via a 68-pin cable (J2-JR/JS/JT connector).
- Module Connectors: 96-pin J3, 48-pin J4 (system connection)
Specifications
|
Parameter |
Details |
|
Model |
IS220PCLAH1B |
|
Belonged System |
GE Mark VIe |
|
Module Type |
|
|
Thermocouple Input Types |
J, K, T and other standard thermocouples |
|
±10V DC, 16-bit resolution |
|
|
Dual 10/100Mbps Ethernet (RJ45) |
|
|
Frame Rate |
10/20/40/80/160/320ms Configurable |
|
Connector Type |
96-pin J3, 48-pin J4 System Connectors |
|
Terminal Board Interface |
68-pin J2 Connector (Connecting to SCLS/SCLT) |
FAQ
Q: What is the brand?
A: GE
Q: What is the type?
A: Core Analog I/O Module
Q: What is the warranty?
A: 1 year
Q: Where is the shipping location?
A: Xiamen
Q: What is the payment method?
A: T/T
