The Epro PR6424/103-021 is a highly precise 16mm Eddy Current Sensor engineered for non-contact measurement of displacement, position, and vibration in various industrial applications. By using the principle of eddy current induction, this sensor offers reliable and accurate measurements, making it ideal for machinery monitoring, vibration analysis, and position sensing in dynamic environments.

The sensor’s 16mm sensor head diameter and 0.2 kg weight ensure compactness and versatility, enabling installation in tight spaces while maintaining exceptional accuracy. With its high-speed response and robust construction, the PR6424/103-021 is well-suited for high-precision applications that require continuous monitoring, such as vibration detection, machinery diagnostics, and real-time position tracking.

Product Specifications

Product Applications

The Epro PR6424/103-021 16mm Eddy Current Sensor is highly versatile, designed for various applications that demand high-precision, non-contact measurement. Some of its key applications include:

1. Vibration Monitoring

   The PR6424/103-021 is used extensively for monitoring vibrations in rotating machinery, motors, turbines, and other high-speed equipment. Early detection of issues like misalignment, imbalance, or wear is crucial for preventing catastrophic failures and ensuring system efficiency.

2. Displacement and Position Sensing

   This sensor provides highly accurate displacement and position measurements, making it ideal for automation, robotics, and assembly lines. It ensures precise control of machinery and components, which is essential for process optimization and quality assurance.

3. Thickness Measurement

   In industries like metalworking and plastics, the PR6424/103-021 is used for non-contact thickness measurement. This sensor helps avoid surface damage while providing reliable data for material control and manufacturing processes.

4. Proximity Sensing

   The sensor detects the presence and position of metallic objects with high precision. It is often used in automated systems to detect components, ensure correct placement, or trigger actions in production processes.

5. Rotational Monitoring

   The PR6424/103-021 is capable of monitoring rotational motion with high accuracy. It is widely used in motors, gears, and pumps to monitor rotational displacement and ensure the proper functioning of rotating parts.

6. Non-Contact Wear Detection

   This sensor can detect wear or deviations in machinery and components without making physical contact, helping to reduce maintenance costs, extend the lifespan of equipment, and improve operational efficiency.

Product Advantages

• High Accuracy

  The PR6424/103-021 offers an impressive ±0.1% full-scale accuracy, providing precise measurements for critical applications that require high performance.

• Non-Contact Measurement

  Utilizing the Eddy Current principle, the sensor delivers non-contact measurement, which prevents wear, contamination, or physical damage to the sensor or target surface, ensuring the reliability and longevity of both.

• Fast Response Time

  The PR6424/103-021 sensor offers a response time of less than 1 ms, making it ideal for dynamic applications that require real-time feedback for immediate adjustments.

• Compact and Lightweight

  The 16mm sensor head diameter and 0.2 kg weight make this sensor compact and easy to install in constrained spaces, without compromising its performance or accuracy.

• Durable and Robust

  With an IP67 rating, the PR6424/103-021 sensor is resistant to dust and water, ensuring reliable performance even in challenging environments where exposure to harsh elements is common.

• Wide Operating Temperature Range

  The sensor can operate in a temperature range of -20°C to +85°C, which makes it suitable for a variety of industrial applications that require reliable performance in both hot and cold environments.

FAQ

1. What is the maximum measuring range of the Epro PR6424/103-021 sensor?

   The PR6424/103-021 can measure up to 10 mm in displacement, making it suitable for small-scale displacement and vibration applications.

2. What output types does the Epro PR6424/103-021 support?

   The sensor supports analog outputs such as 4-20mA and 0-10V, which are compatible with most industrial control systems.

3. What is the accuracy of the Epro PR6424/103-021 sensor?

   The PR6424/103-021 sensor offers ±0.1% full-scale accuracy, providing high precision for demanding measurement tasks.

4. What is the response time of the Epro PR6424/103-021 sensor?

   The response time is less than 1 ms, making it ideal for applications that require fast feedback and real-time monitoring.

5. What material is the sensor head made of?

   The sensor head is made from stainless steel, ensuring durability, resistance to corrosion, and high reliability in harsh industrial environments.

6. What is the environmental rating of the Epro PR6424/103-021 sensor?

   The PR6424/103-021 sensor is rated IP67, meaning it is protected against dust and can withstand immersion in water, making it suitable for challenging environments.

7. What is the operating voltage of the Epro PR6424/103-021 sensor?

   The sensor operates on 24V DC, which is a standard voltage for industrial sensors, making it easy to integrate with existing systems.

8. What is the temperature range for the Epro PR6424/103-021 sensor?

   The PR6424/103-021 sensor operates in a temperature range of -20°C to +85°C, making it adaptable to a wide range of industrial environments.

9. How is the Epro PR6424/103-021 sensor mounted?

   The sensor uses threaded mounting, which is adjustable for precise positioning during installation.

10. Can the Epro PR6424/103-021 sensor be used for high-speed monitoring?

    Yes, with a response time of less than 1 ms, the PR6424/103-021 is ideal for high-speed applications requiring quick adjustments and real-time feedback.
