Emerson PR6423/015-111 CON041 Eddy Current Signal Converter
Product Number: PR6423/015-111 + CON041
Category: Eddy Current Sensor System with Converter
System Platform: MMS 3000/6000 Machinery Monitoring Systems
Sensor Type: 8mm eddy current displacement sensor
Probe Length: 1.5 meters (specified by -015- suffix)
Cable Length: 11.1 meters (specified by -111 suffix)
Converter: CON041 signal converter (2-wire 4-20 mA output)
Application: Shaft vibration monitoring, position measurement, rotating machinery protection
Product Description
Emerson EPRO PR6423/015-111 CON041 Eddy Current Signal Converter designed for critical turbo machinery applications such as steam, gas and hydro turbines, compressors, pumps and fans to measure radial and axial shaft displacement, position, eccentricity and speed/key
Dynamic Performance
- Frequency Range (-3 dB): 0 to 20,000 Hz
- Rise Time: <15µs
Compatibility
- Designed for PR6422, PR6423, PR6424, PR6425, PR6426
- For Extended Range Use: CON041/91x-xxx
- PR6425 Requires Extended Range Converter
Environmental
- Operating Temperature Range: -30 to 100°C (-22 to 212°F)
- Shock and Vibration: 5g @ 60Hz @ 25°C (77°F)
- Protection Class: IP20
Power & Electrical
-
Supply Voltage Range:
- For Output Range -4V to -20V: -23V to -32V
- For Output Range -2V to -18V: -21V to -32V
Physical
- Housing Material / Weight: PA 6.6 / ~60 grams (2.12 oz)
- Mounting: Din Rail
- Connections: Screw Terminal (Max. 1.5mm2, Wire-end Sleeves)
