The ABB PM810V2 3BSE013220R1 is a highly efficient and powerful CPU processor module designed for industrial automation applications. As part of the ABB 800xA Distributed Control System (DCS), the PM810V2 module provides robust control, flexibility, and scalability for industrial systems. This CPU module is engineered to provide high-speed processing for complex automation tasks while ensuring reliable and secure operation in critical control environments.

The PM810V2 CPU processor module is designed to meet the requirements of a wide range of industries, including process automation, power generation, water treatment, manufacturing, and more. It features advanced communication protocols, a compact design, and high-performance processing capabilities to handle complex control functions. With the ability to integrate seamlessly with ABB’s I/O modules and field devices, the PM810V2 is a versatile solution for modern industrial automation.

The module provides excellent fault tolerance and redundancy options, ensuring continuous, uninterrupted control in mission-critical systems. It is built for long-term reliability and low-maintenance performance, reducing system downtime and enhancing operational efficiency.

Technical Specifications

Applications

The ABB PM810V2 CPU Processor Module is ideal for a broad range of industrial applications that require high-speed processing, flexible communication, and real-time control. Some of the most common applications include:

• Process Automation: Managing complex industrial processes such as chemical reactions, power generation, and refinery operations.

• Power Generation: Controlling and monitoring turbines, generators, and other critical equipment in power plants.

• Water and Wastewater Treatment: Ensuring reliable operation of water treatment plants, sewage treatment systems, and pumping stations.

• Manufacturing Automation: Optimizing production lines, robotic systems, and other automated manufacturing processes.

• Building Automation: Managing HVAC, lighting, and security systems in large commercial and industrial buildings.

• Energy Management: Monitoring energy consumption, distribution, and efficiency in large industrial facilities.

Key Advantages

• High-Speed Processing: The PM810V2 features advanced processor technology that ensures fast execution of complex tasks, ideal for applications with real-time requirements.

• Versatile Communication: The module supports various communication protocols such as Ethernet, Profibus, Modbus, and RS232/RS485, allowing for seamless integration with other systems and devices.

• Compact Design: With a compact form factor of 210 × 160 × 90 mm, the PM810V2 can be easily integrated into installations with limited space while maintaining high performance.

• Reliability and Durability: Built to operate in industrial environments, the PM810V2 is designed for long-term reliability, minimizing downtime and maintenance needs.

• Scalability: The PM810V2 can be easily expanded with ABB’s range of I/O modules, allowing it to scale as the needs of the system grow.

• Real-Time Control: The integrated real-time clock and high-speed processing capabilities ensure that critical systems are controlled precisely and on time.

• Flexible Programming: The PM810V2 supports IEC 61131-3 programming languages (Ladder Diagram, Function Block Diagram, Structured Text, etc.), providing flexibility in system design and programming.

• Redundancy and Fault Tolerance: The PM810V2 offers redundancy options to ensure continuous control even in the event of hardware failures, making it perfect for mission-critical applications.

• Energy Efficiency: The module is designed to optimize energy usage, making it an energy-efficient solution for automation systems.

• Safety Standards Compliance: The PM810V2 meets international safety certifications, including UL, CE, IECEx, and ATEX, ensuring its suitability for hazardous environments.

Frequently Asked Questions (FAQ)

1. What communication protocols are supported by the PM810V2?

   The PM810V2 supports Ethernet, Profibus, Modbus, and RS232/RS485 communication protocols.

2. What is the power supply requirement for the PM810V2?

   The PM810V2 requires a 24 VDC power supply.

3. What is the weight of the PM810V2?

   The PM810V2 weighs 0.6 kg.

4. What are the dimensions of the PM810V2?

   The dimensions of the PM810V2 are 210 × 160 × 90 mm.

5. What is the operating temperature range for the PM810V2?

   The operating temperature range is from 0°C to +60°C.

6. Can the PM810V2 be expanded with additional I/O modules?

   Yes, the PM810V2 can be expanded using ABB I/O modules.

7. What programming languages are supported by the PM810V2?

   The PM810V2 supports IEC 61131-3 programming languages, including Ladder Diagram (LD), Function Block Diagram (FBD), and Structured Text (ST).

8. What memory does the PM810V2 have?

   The PM810V2 has 1 MB of program memory, which is expandable.

9. Is the PM810V2 suitable for hazardous environments?

   Yes, the PM810V2 is certified for use in hazardous environments with UL, CE, IECEx, and ATEX certifications.

10. How does the PM810V2 ensure real-time control?

    The PM810V2 integrates a real-time clock and features high-speed processing, ensuring that time-sensitive tasks are executed precisely and on time.
