The Honeywell TC-IAH061 is a High Level Analog Input Module designed for the Experion LS platform, providing precise and reliable measurement of high-level analog signals in industrial process control environments. This module converts analog inputs from field devices such as transmitters and sensors into digital signals that can be processed by the control system for monitoring and automation purposes.

The TC-IAH061 module supports a wide range of input types and is engineered to deliver high accuracy, stability, and noise immunity. Its robust design ensures dependable performance even in harsh industrial conditions, making it a critical component in the Honeywell Experion LS distributed control system (DCS).

Key Features

• High level analog input signal processing for accurate data acquisition.

• Supports multiple input ranges including voltage and current signals.

• Compatible with Experion LS distributed control systems.

• High accuracy and stability for precise process control.

• Advanced noise filtering and signal conditioning.

• Supports hot-swappable installation to minimize downtime.

• Diagnostic capabilities for fault detection and troubleshooting.

• Robust design suitable for industrial environments.

• Compact size for efficient rack mounting.

• Complies with industrial standards and certifications.

Technical Specifications

Industry Applications

• Oil & Gas: Monitoring of pressure, temperature, and flow via analog sensors.

• Chemical Processing: Precise measurement of process variables for control and safety.

• Power Generation: Monitoring critical analog signals from turbines and boilers.

• Water & Wastewater: Measuring chemical dosing and flow control signals.

• Pharmaceutical Manufacturing: High-accuracy analog inputs for batch and process control.

• Food & Beverage: Reliable analog data acquisition for quality control and process automation.

Product Advantages

• High Precision: Enables accurate measurement critical for effective process control.

• Versatile Input Support: Accommodates a variety of analog signal types and ranges.

• Robust and Reliable: Designed to withstand industrial environmental challenges.

• Ease of Maintenance: Hot-swappable design minimizes downtime during servicing.

• Diagnostic Features: Built-in diagnostics improve fault detection and reduce troubleshooting time.

• Compact Form Factor: Saves valuable space within control racks.

• Seamless Integration: Fully compatible with Honeywell Experion LS systems for simplified deployment.

• Noise Immunity: Advanced filtering ensures signal integrity in electrically noisy environments.

• Compliance: Meets industry safety and quality standards.

• Enhanced System Performance: Supports stable and consistent process monitoring and control.

Frequently Asked Questions (FAQ)

1. What input signals does the TC-IAH061 support?

   It supports voltage inputs (0-10 V, 1-5 V, ±10 V, ±5 V) and current inputs (0-20 mA, 4-20 mA).

2. How many channels are available on this module?

   Typically, it supports 8 analog input channels.

3. What is the accuracy of the module?

   The accuracy is ±0.1% of full scale.

4. Is the module hot-swappable?

   Yes, it can be replaced without shutting down the control system.

5. What is the operating temperature range?

   It operates reliably between 0°C and +60°C.

6. How does the module communicate with the control system?

   It uses a proprietary communication bus compatible with Experion LS systems.

7. What diagnostic features are included?

   The module includes fault detection and status monitoring to aid troubleshooting.

8. What is the module’s resolution?

   It features 16-bit analog-to-digital conversion for precise measurement.

9. Is the module suitable for harsh industrial environments?

   Yes, it is designed to withstand typical industrial temperature and humidity ranges.

10. Which Honeywell systems is it compatible with?

    It is designed specifically for the Honeywell Experion LS distributed control system.
