Whether used in manufacturing, energy, transportation, or infrastructure projects, this CPU provides reliability and scalability to support complex automation systems with high-speed execution and superior networking features.

Product Features

• High-Speed Processor: Equipped with an Intel Pentium-class processor for rapid logic execution.

• Large Memory Capacity: Includes 64 MB user memory and expandable memory capabilities.

• Integrated Ethernet Ports: Dual Ethernet interfaces for programming, HMI/SCADA, and peer-to-peer communication.

• Compatibility: Supports RX7i modules and backplanes, making upgrades or expansions simple.

• Real-Time Clock: Battery-backed clock for time-sensitive applications and accurate event stamping.

• Robust Programming Support: Compatible with Proficy Machine Edition for programming and configuration.

• Advanced Diagnostics: Built-in LED indicators and software-based diagnostics for easy troubleshooting.

• Secure Data Handling: Non-volatile memory protects programs and data in case of power loss.

Technical Specifications

Product Applications

• Factory Automation: Suitable for high-speed, synchronized machine control.

• Process Control: Used in batch and continuous process environments like chemical, food, and beverage industries.

• Power Generation: Applied in turbine and substation automation systems.

• Transportation: Integral to train control systems and smart traffic management.

• Oil & Gas: Used in upstream drilling, midstream pipelines, and downstream refining automation.

• Water Treatment: Critical for controlling filtration, pumping, and chemical dosing systems.

Product Advantages

• Exceptional Processing Speed: Delivers faster scan rates and deterministic control for critical operations.

• Flexible Communication: Multiple Ethernet and serial ports allow seamless data integration and remote diagnostics.

• Expandable and Scalable: Easily fits into expanding industrial setups without hardware overhaul.

• Industrial-Grade Reliability: Withstands harsh industrial environments with high durability.

• Simplified Maintenance: Integrated diagnostics reduce downtime and simplify maintenance routines.

• Secure Data Storage: Built-in flash ensures program integrity even during power interruptions.

Frequently Asked Questions (FAQ)

Q1: What software is used to program the IC698CPE020?

A1: The CPU is programmed using GE’s Proficy Machine Edition software.

Q2: Can this CPU be used with other RX7i modules?

A2: Yes, the IC698CPE020 is fully compatible with RX7i I/O modules and backplanes.

Q3: How much user memory does the module have?

A3: It provides 64 MB of user memory for application programs and data.

Q4: Does the module support remote programming?

A4: Yes, it has built-in Ethernet ports for remote programming and monitoring.

Q5: What type of processor is integrated in the IC698CPE020?

A5: It uses a Pentium-class processor running at 300 MHz.

Q6: Is the real-time clock battery-backed?

A6: Yes, the clock is backed by a battery for uninterrupted timekeeping.

Q7: What is the module’s power consumption?

A7: It consumes approximately 1.5 Amps at 5 VDC.

Q8: Can this module operate in extreme environments?

A8: Yes, it is designed to operate within a temperature range of 0 to 60 °C and withstand up to 95% humidity.

Q9: Does the CPU support firmware updates?

A9: Yes, firmware can be updated via Proficy software or Ethernet interface.

Q10: Is there LED status indication on the module?

A10: Yes, it features front-panel LEDs for CPU status and diagnostics.
