ABB DSPC 172H 57310001-MP DS Processor Board

The ABB DSPC 172H (57310001-MP) is a high-performance DS Processor Board designed for critical process control tasks within ABB’s Advant OCS and Symphony DCS platforms. Engineered for fast and reliable computation, this processor board plays a key role in managing control logic, inter-system communication, and automation tasks in industrial environments. It is favored for installations that require robust performance, enhanced communication capability, and stable operation over extended durations.

Built to ABB’s exacting industrial standards, the DSPC 172H integrates seamlessly into existing DCS architectures, ensuring both compatibility and future scalability. This makes it an ideal choice for system upgrades, modernizations, or greenfield projects requiring dependable processing hardware.

Product Specifications

Product Applications

The DSPC 172H board is specifically designed for demanding process automation scenarios. It provides the real-time computational power required to ensure stable, safe, and efficient control over large industrial systems. Typical application sectors include:

• Power Generation (fossil, hydro, nuclear, and renewable plants)

• Chemical & Petrochemical Industries

• Oil and Gas Refineries and Pipelines

• Water Treatment and Desalination Plants

• Steel and Metals Production

• Paper and Pulp Manufacturing

• Pharmaceutical Manufacturing

• Industrial Automation Lines (Discrete and Process)

Its extended memory and redundancy capabilities make it particularly suited to complex DCS environments involving thousands of I/O points and safety interlocks.

Key Product Advantages

• High-Speed Processing: Optimized for fast control response and complex logic operations.

• Extended Memory Support: Capable of handling large control programs and data logs.

• Full Redundancy Support: Enables seamless switchover in case of failure, increasing system availability.

• Seamless Integration: Fully compatible with ABB’s legacy and modern platforms including Symphony Plus.

• Compact and Efficient: Designed to fit in Eurocard rack systems, allowing easy replacement and upgrades.

• Low Maintenance: Robust industrial design minimizes failure rates; diagnostic LEDs simplify fault tracing.

• Scalable Control: Adaptable to systems of varying sizes, from small batch processes to large-scale power plants.

• ABB Lifecycle Support: Backed by ABB’s extended availability of spares and field service.

• Proven Performance: Trusted across thousands of installations worldwide over decades.
