General Electric IC695ETM001 RX3i Ethernet Interface Module

The GE IC695ETM001 Ethernet Interface Module is designed specifically for the RX3i series of programmable automation controllers (PACs). It provides a reliable and high-performance Ethernet communication interface that integrates seamlessly with GE’s RX3i control system, enabling industrial networks to achieve faster data transfer, enhanced connectivity, and improved system flexibility.

Built with robust industrial-grade components, the IC695ETM001 supports multiple Ethernet protocols, including Modbus TCP/IP and GE’s proprietary Ethernet protocols, allowing versatile communication options across different devices and networks. The module enhances system diagnostics and supports remote programming, monitoring, and troubleshooting, facilitating reduced downtime and maintenance costs.

Product Specifications

Product Applications

• Industrial Automation Networks: Facilitates communication between RX3i PACs and Ethernet-based devices in manufacturing lines, process control, and factory automation.

• Remote Monitoring and Control: Enables operators and engineers to access control systems remotely for diagnostics, programming, and troubleshooting.

• Data Acquisition Systems: Collects and transfers data from field devices to supervisory control and data acquisition (SCADA) systems.

• System Integration: Connects various industrial devices and subsystems via Ethernet, supporting multi-vendor interoperability.

• Redundant Network Architectures: Supports network redundancy strategies for enhanced system reliability.

• OEM Equipment: Embedded in custom industrial machines requiring robust Ethernet communications.

Product Advantages

• Seamless Integration with RX3i Platform: Fully compatible with GE’s RX3i PACs, ensuring smooth communication without additional hardware.

• High-Speed Data Transfer: Supports 10/100 Mbps Ethernet to enable rapid and efficient communication.

• Versatile Protocol Support: Works with standard Modbus TCP/IP and GE’s Ethernet protocols for flexible industrial communication.

• Improved Diagnostics and Monitoring: Offers extensive diagnostic features, helping identify network issues quickly.

• Compact and Rugged Design: Small footprint and durable build suited for harsh industrial environments.

• Low Power Consumption: Operates efficiently, reducing overall energy costs in automated systems.

• Simplifies Remote Access: Facilitates remote programming and maintenance, reducing the need for onsite visits.

• Compliance with Industry Standards: Meets global certification requirements ensuring safety and reliability.

• Easy Installation: Designed for simple mounting on DIN rails or backplanes, speeding up deployment.

• Reliable Network Performance: Provides stable and consistent Ethernet communication, minimizing network downtime.

Frequently Asked Questions (FAQ)

1. What types of Ethernet protocols does the IC695ETM001 support?

   The module supports Modbus TCP/IP and GE’s proprietary Ethernet protocols to ensure flexible communication options.

2. Can the IC695ETM001 be used with other GE PAC series?

   This module is specifically designed for the RX3i series and may not be compatible with other GE PAC families.

3. What is the maximum operating temperature for the Ethernet Interface Module?

   It operates reliably within the temperature range of 0 to 60 °C (32 to 140 °F).

4. Is the IC695ETM001 capable of remote diagnostics?

   Yes, it supports remote monitoring and diagnostics, which aids in faster troubleshooting and maintenance.

5. How is the IC695ETM001 powered?

   It receives 5 V DC power through the RX3i backplane, requiring no additional external power supply.

6. What is the data transfer speed supported by the module?

   The module supports 10/100 Mbps Ethernet communication speeds.

7. Can this module be mounted on a standard DIN rail?

   Yes, it is designed for mounting on DIN rails or directly on the RX3i backplane.

8. What are the physical dimensions of the IC695ETM001?

   The module measures 135 x 129 x 53 mm.

9. Does the module require any special software for configuration?

   Configuration is typically performed through GE’s programming environment, such as Proficy Machine Edition.

10. Is the IC695ETM001 compliant with international safety and environmental standards?

    Yes, it complies with CE, UL, and RoHS standards.
