Schneider TSXMRPC001M Configurable SRAM Application Memory Extension

The Schneider TSXMRPC001M is a Configurable SRAM Application Memory Extension designed to enhance the memory capacity of Schneider Electric’s Modicon Quantum and Modicon Premium PLCs. This memory extension module is critical in applications that require large amounts of memory for data processing, storing, and real-time performance. The module integrates seamlessly with the PLC, providing additional SRAM storage for sophisticated applications, ensuring optimal performance in demanding environments.

By incorporating the TSXMRPC001M, users can achieve expanded memory configurations that allow for more complex programs, larger data storage, and faster data processing. This is essential for industries where large-scale automation, real-time control, and data management are crucial for operations such as in manufacturing, energy, and process industries.

Product Specifications

Product Applications

The Schneider TSXMRPC001M Configurable SRAM Application Memory Extension is ideal for a wide range of industrial automation applications where large memory capacity is required for efficient control and data management. Some of the key areas where this product is used include:

• Industrial Automation: Enhancing the memory capability of control systems to store larger programs, manage more variables, and ensure faster processing times.

• Process Control: Used in industries such as oil & gas, chemical, and pharmaceutical where complex control algorithms and large datasets need to be processed in real time.

• Manufacturing Systems: Expands memory for systems managing high-speed, real-time data, especially in production lines and assembly automation.

• Building Automation: Suitable for systems controlling multiple building functions like HVAC, lighting, and security, where scalability and memory expansion are key.

• Energy and Utilities: Critical in managing large amounts of data in power grids, renewable energy systems, and smart grid applications where fast, real-time processing is necessary.

Product Advantages

1. Enhanced Memory Capacity: The TSXMRPC001M provides 1 MB of additional SRAM, ensuring that memory-intensive applications can run smoothly without compromising performance.

2. Configurable Design: This module can be configured to meet the specific needs of different applications, allowing for more flexible system design and scalability.

3. Improved Performance: The addition of SRAM accelerates data access times, resulting in faster processing and execution of control programs.

4. Seamless Integration: It is fully compatible with Modicon Quantum and Premium PLCs, ensuring easy integration without complex setup.

5. High Reliability: With its non-volatile storage, the module guarantees data retention even in the event of a power failure, ensuring system stability.

6. Compact Form Factor: Despite its high memory capacity, the module’s small size allows it to fit in spaces where larger modules might not.

7. Energy Efficient: Consumes only 5 W of power, making it a highly energy-efficient memory extension for industrial applications.

8. Easy Installation: The module mounts directly on a DIN rail, making installation quick and straightforward for maintenance engineers and system integrators.

9. Robust Design: Rated with IP20, it is built to withstand the challenges of industrial environments, ensuring reliable operation over extended periods.

10. Cost-Effective Memory Expansion: Offers a highly cost-efficient solution for enhancing memory without the need for a full system upgrade.
