Woodward 5417-175 Cable Assembly

The Woodward 5417-175 Cable Assembly is a precision-engineered industrial-grade cable designed specifically to ensure reliable connectivity within Woodward control systems. Known for their uncompromising quality and performance, Woodward Cable Assemblies like the 5417-175 serve as vital components in connecting controllers, modules, and peripheral devices in demanding environments such as power plants, turbine control systems, and industrial automation.

Built to meet stringent electrical, mechanical, and environmental standards, the 5417-175 Cable Assembly offers excellent signal integrity, robust mechanical protection, and superior electromagnetic shielding. Whether deployed in high-vibration turbine enclosures or process control panels, this cable assembly ensures seamless data and power transmission, minimizing signal losses and maintaining operational reliability.

Product Parameters

Applications

The Woodward 5417-175 Cable Assembly is designed to serve critical connectivity roles in a wide range of industrial applications, including:

• Gas Turbine Control Systems

  • Connecting the governor and actuator interfaces

  • Facilitating signal transmission between control modules

• Steam Turbine Control

  • Power and signal transmission between the controller and field devices

• Generator Set Control

  • Ensuring data and power integrity for voltage regulation and synchronization

• Industrial Engine Control

  • Supporting closed-loop control systems with precise, noise-immune signal paths

• Process Automation Panels

  • Reliable wiring between I/O modules, PLCs, and sensors

• Substation Automation

  • Used in high-voltage environments for protective relay communication

Product Advantages

• High Signal Integrity

  Shielded and twisted-pair conductors prevent EMI/RFI interference, ensuring accurate data transmission.

• Robust Construction

  Built with rugged materials to endure harsh industrial environments including high vibration, oil exposure, and temperature extremes.

• Factory-Terminated & Tested

  Pre-assembled connectors minimize installation errors and ensure plug-and-play performance.

• Durable Jacket

  Industrial-grade insulation offers excellent abrasion resistance and longevity.

• Highly Flexible

  Maintains flexibility across temperature extremes; suitable for use in dynamic cable applications.

• Environmental Protection

  IP67-rated when properly connected, providing excellent protection against dust and moisture ingress.

• Compatibility

  Fully compatible with Woodward control platforms and certified for use with multiple Woodward controller series.

• Easy Maintenance

  Modular replacement reduces downtime and simplifies maintenance routines.

• Globally Approved

  CE and UL approved materials ensure suitability for international markets.

• Long Service Life

  Engineered for extended operational lifetime even in mission-critical applications.

FAQ

1. What is the primary use of the 5417-175 Cable Assembly?

   It is used for connecting control modules, actuators, and sensors within Woodward turbine, generator, and engine control systems.

2. What type of connectors are used in this assembly?

   The cable is terminated with factory-tested proprietary connectors suitable for Woodward control platforms.

3. Can this cable assembly be customized in length?

   Yes, standard lengths such as 12 feet are available, and custom lengths can be ordered based on application needs.

4. Does the cable provide shielding against electrical noise?

   Yes, it features a full braided shield combined with foil wrap for superior EMI/RFI protection.

5. Is the cable suitable for dynamic (moving) applications?

   Yes, the cable’s flexibility and robust jacket allow for dynamic applications, including moving assemblies and articulated control cabinets.

6. What certifications does the cable comply with?

   The cable is made from CE, UL, and RoHS-compliant materials suitable for global installations.

7. Is this cable compatible with Woodward GAP-configured control systems?

   Yes, it is designed for compatibility with various Woodward GAP (Graphical Application Programmer) based control solutions.

8. Can the 5417-175 withstand exposure to oils and industrial chemicals?

   Yes, the outer jacket material is oil-resistant and rated for use in harsh industrial environments.

9. What is the maximum voltage rating of this cable?

   The cable is rated for up to 300 V, suitable for most low-voltage signal and control circuits.

10. What is the IP rating when fully connected?

    When mated with the appropriate connectors, the assembly provides IP67-level ingress protection.
