Schneider 140CFJ00400 Analog Output Block

The Schneider 140CFJ00400 Analog Output Block is a high-performance output module designed for the Schneider Modicon Quantum PLC platform. It provides precise, reliable analog output signals for controlling field devices such as actuators, control valves, variable speed drives, and instrumentation in a wide range of industrial automation systems.

Engineered to deliver consistent performance under demanding conditions, the 140CFJ00400 outputs analog signals with excellent accuracy and stability, making it an essential component for applications where precise analog control is required. The module is designed to work seamlessly within the Quantum automation environment and is fully compatible with Schneider Electric’s Unity Pro/Control Expert programming software.

With robust electrical isolation, extensive diagnostics, and an industrial-grade construction, this analog output block helps engineers achieve tight process control, smooth equipment operation, and reliable performance across diverse industry sectors.

Product Specifications

Applications

The Schneider 140CFJ00400 Analog Output Block is widely used in industrial sectors where precision analog control is essential:

• Process Control: Chemical plants, refineries, water treatment facilities.

• Manufacturing Automation: Control of actuators, dampers, and drive systems.

• Building Automation: HVAC control, lighting management.

• Energy Sector: Power generation, oil & gas, renewable energy systems.

• Food & Beverage: Temperature, flow, and pressure control in production lines.

• Pharmaceuticals: Precision dosing, temperature control, batch processing.

• Pulp and Paper: Process automation and equipment control.

• Mining & Metals: Motorized valve and actuator control.

Advantages

• High Accuracy: ±0.1% accuracy ensures precise control of field devices.

• Robust Isolation: Electrical isolation protects equipment and ensures safe operation.

• Fast Response: 5 ms update rate enables quick and responsive control.

• Diagnostic Features: On-board diagnostics help minimize downtime and support predictive maintenance.

• Compact Footprint: Saves valuable rack space while delivering full functionality.

• Seamless Integration: Fully compatible with Schneider’s Modicon Quantum PLC platform and software tools.

• Wide Temperature Range: Suitable for harsh industrial environments.

• Flexible Output Range: 4–20 mA output supports a broad range of industrial devices.

• CE/UL/CSA Certified: Meets global standards for safety and reliability.

• Proven Reliability: Industrial-grade construction ensures long service life.

Frequently Asked Questions (FAQ)

1. What type of signal does the 140CFJ00400 output?

   It provides a 4–20 mA current analog output.

2. How many analog outputs does this module support?

   The module supports 4 independent analog output channels.

3. Is the module isolated?

   Yes, it offers 1780 V RMS isolation between channels and the backplane.

4. What is the resolution of each output?

   The outputs are 12-bit resolution.

5. What is the compatible PLC platform for this module?

   It is designed for use with Schneider Modicon Quantum PLCs.

6. What kind of field devices can this module control?

   It can control actuators, control valves, drives, and any other 4–20 mA devices.

7. What is the typical response time for output updates?

   It provides an update rate of 5 ms per channel.

8. Does it have built-in diagnostics?

   Yes, it includes channel diagnostics and open-circuit detection.

9. Is this module suitable for harsh environments?

   Yes, it operates from 0°C to +60°C and supports high humidity and vibration.

10. Can this module be used with Unity Pro/Control Expert software?

    Yes, it is fully supported by Schneider’s Unity Pro/Control Expert.
