General Electric IC660BBR101 16-Circuit Relay Output Block
Item Number:IC660BBR101
Brand: GE
Lead Time: In stock
Description:16-Circuit Relay Output Block
Payment: T/T
Product Description
GE IC660BBR101 is a 16-way relay output module with a normally open contact design. The module is divided into 4 independent output groups, each group contains 4 relay output circuits, and the module's power supply voltage can be 115V AC or 230V AC.
There are two main types of relay output modules:
Normal closed contact relay output module (model IC66*BBR100)
Normal open contact relay output module (model IC66*BBR101, that is, this module)
Function & Features
- Independent power supply for each group: Each 4 outputs (i.e. each group) on the IC660BBR101 module can be powered by an independent AC or DC power supply, and the isolation voltage between groups is up to 1500 volts.
- Output state management: IC660BBR101 has the output power-on default state function, which supports the output to maintain the last state or restore the default state.
- Redundancy and control: IC660BBR101 supports CPU redundancy type, which can be controlled by the bus switching module.
Specifications
| Parameter | Details |
|---|---|
| Model | IC660BBR101 |
| Frequency | 47-63 Hz |
| Operating voltage | (115VAC) 93 to 132VAC; (230VAC) 185 to 265VAC |
| Power requirement | 87mA at 115 VAC |
| Power supply dropout time | 1 cycle |
| Size (height x width x depth) | 8.83" (22.44cm) x 3.34" (8.48cm) x 3.91" (9.93cm) |
| Weight | 4 lbs. (1.8 kg) |
| LEDs (I/O Block) | Unit OK, I/O Enabled |
| LEDs (each circuit) | Individual relay coil state |
FAQ
Q: What is the brand?
A: GE
Q: What is the type?
A: 16-Circuit Relay Output Block
Q: What is the warranty?
A: 1 year
Q: Where is the shipping location?
A: Xiamen
Q: What is the payment method?
A: T/T
