General Electric IC698CRE020CA Chassis/Rack Module

The GE IC698CRE020CA is a core 20-slot chassis module in GE’s PACSystems RX3i series, designed to serve as the physical and electrical backbone for modular industrial automation systems. As a rack module, it provides standardized slots for integrating RX3i I/O modules (analog, digital, specialty), communication modules (Ethernet, Profinet, Modbus), and compatible power supplies, enabling flexible system configuration tailored to specific application needs.

By centralizing module mounting and signal routing, the GE IC698CRE020CA ensures stable power distribution and reliable data transmission between connected components, making it ideal for medium to large-scale automation projects. Its design aligns with GE’s PACSystems RX3i ecosystem, which emphasizes scalability and interoperability, allowing users to expand or modify their control systems without replacing the entire chassis—delivering long-term value and adaptability for industrial operations.

Detailed Parameter Table

Core Advantages and Technical Highlights

Scalable slot configuration: The GE IC698CRE020CA offers 20 dedicated slots, a significant upgrade over smaller RX3i chassis models (e.g., 5-slot or 10-slot variants). This capacity supports large-scale I/O integration, enabling users to connect up to 20 compatible modules (including mixed I/O and communication types) in a single rack—reducing the need for multiple chassis and simplifying system architecture.

Industrial-grade durability: Built to withstand harsh factory environments, the GE IC698CRE020CA meets strict vibration (5 g peak) and shock (30 g peak) resistance standards, along with a wide operating temperature range (0°C to 60°C). Its robust construction minimizes downtime caused by environmental stress, ensuring continuous operation in sectors like manufacturing, oil and gas, and power generation.

Seamless ecosystem compatibility: The GE IC698CRE020CA is fully compatible with all GE PACSystems RX3i components, including CPUs (e.g., IC698CPU310), power supplies (e.g., IC698PWR320), and I/O modules (e.g., IC698MDL754). This compatibility eliminates integration issues, allowing users to leverage existing RX3i investments while scaling their systems—reducing setup time and operational costs.

Rack-mount efficiency: Designed for 19-inch standard racks, the GE IC698CRE020CA optimizes space utilization in control cabinets. Its 1U height compatibility ensures it fits alongside other rack-mountable industrial equipment, while clearly labeled slot positions simplify module installation and maintenance—enhancing overall system manageability.

Typical Application Scenarios

The GE IC698CRE020CA excels in medium to large-scale industrial automation projects where centralized, scalable control is critical. In automotive manufacturing, for example, it serves as the chassis for integrating digital I/O modules (to monitor assembly line sensors) and communication modules (to connect to PLCs and MES systems), enabling real-time coordination of production processes and reducing bottlenecks.

In oil and gas upstream operations, the GE IC698CRE020CA withstands harsh environmental conditions (extreme temperatures, vibration from pumps) while housing analog I/O modules (to measure pressure, flow, and temperature) and safety-related modules. This ensures reliable monitoring of wellhead equipment and compliance with industry safety standards, minimizing the risk of unplanned downtime.

For water and wastewater treatment plants, the GE IC698CRE020CA supports the integration of specialty I/O modules (e.g., for pH or turbidity sensors) and Ethernet communication modules, facilitating remote monitoring and control of treatment processes. Its scalable slot design allows plants to expand their systems as capacity increases, ensuring long-term adaptability to changing operational needs.

Installation Commissioning and Maintenance Instructions

Installation preparation: Before installing the GE IC698CRE020CA, ensure the 19-inch rack is level, stable, and rated to support the module’s weight (approx. 3.5 kg). Gather tools including a torque wrench (to secure mounting screws to 4.5 N·m), anti-static wristband (to prevent electrostatic damage), and a level (to align the chassis). Verify the installation environment meets the module’s temperature (0°C to 60°C) and humidity (5% to 95% non-condensing) requirements. Avoid mounting near heat sources (e.g., power inverters) or areas with excessive dust, as this can degrade performance.

Maintenance suggestions: For daily maintenance of the GE IC698CRE020CA, inspect the chassis monthly for loose module connections—gently push each module to ensure it is fully seated in its slot. Use compressed air (low pressure, <50 psi) to clean dust from ventilation slots, preventing overheating. If a module fails, power off the chassis before replacing it to avoid electrical damage. Keep a stock of compatible spare parts (e.g., GE IC698PWR320 power supplies) to minimize downtime. Annual checks should include verifying compliance with environmental standards and testing vibration resistance (if the chassis is in a high-vibration area) to ensure long-term reliability.

Service and Guarantee Commitment

The GE IC698CRE020CA comes with a 2-year standard manufacturer’s warranty, covering defects in materials and workmanship under normal use. GE Industrial Solutions guarantees that the GE IC698CRE020CA will meet all published technical specifications during the warranty period, with free repair or replacement for qualifying issues.

Beyond warranty, GE offers global technical support for the GE IC698CRE020CA, including 24/7 access to certified engineers via phone and email, as well as online resources (user manuals, troubleshooting guides, and firmware updates). For customers requiring extended coverage, GE provides customizable service contracts that include preventive maintenance, priority repair, and on-site support—ensuring minimal downtime for critical automation systems. GE’s commitment to quality ensures that the GE IC698CRE020CA delivers consistent performance, backed by a partner with decades of experience in industrial control solutions.
