Schneider STBACO0220 Standard Analog Output Modules
Manufacturer: Schneider Electric
Product Number: STBACO0220
Category: Standard Analog Output Module (Modicon STB series)
Number of Channels: 2 (typical)
Output Signal: 4-20 mA, 0-10 V
Resolution: 12-bit or 16-bit
System Compatibility: Modicon STB series distributed control systems
Product Description
The Schneider STBACO0220 Standard Analog Output Module is designed for use within Schneider Electric’s Modicon STB series distributed control systems. This module is specifically developed to provide precise analog output signals for various industrial control applications, ensuring consistent performance and reliability in critical operations. The STBACO0220 is widely used in applications such as process control, automation systems, and machine control where high accuracy and real-time performance are crucial.
Built to seamlessly integrate with Schneider Electric’s Modicon controllers and I/O systems, the STBACO0220 offers enhanced scalability and flexibility, supporting multiple output ranges and configurations for various industrial applications.
Key Features
-
High Precision Output–Provides precise 0–10 V DC or 4–20 mA analog outputs, ideal for process control and instrumentation applications
-
Flexible Configuration–Configurable to a wide range of applications with support for multiple output ranges
-
Modular Design–Compatible with the Modicon STB modular I/O system, allowing for easy integration and expansion of your system
-
Real-Time Performance–Ensures continuous and accurate output control for real-time processing and monitoring
-
Robust Industrial Design–Built to withstand harsh environments with protection against dust and moisture, ensuring reliable operation in industrial conditions
-
Compact Form Factor–Space-efficient design for use in constrained spaces within control cabinets and panels
Technical Specifications
Dimensions and Weight
| Item | Specification |
|---|---|
| Dimensions | 70 x 18.4 x 128.3 mm |
| Weight | 0.059 kg |
Electrical Characteristics
| Item | Specification |
|---|---|
| Output Type | 4–20 mA / 0–10 V DC |
| Output Resolution | 12-bit |
| Maximum Output Load | 500 Ω (for 4–20 mA) |
| Power Consumption | Approx. 1 W |
| Input Voltage | 24 V DC ± 20% |
| Communication | Modbus (via Modicon STB system) |
Environmental Characteristics
| Item | Specification |
|---|---|
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5%–95% RH (non-condensing) |
| Enclosure Rating | IP20 (for indoor use) |
System Compatibility
| Item | Specification |
|---|---|
| Supported Systems | Modicon STB distributed I/O system |
| Communication Protocol | Modbus RTU |
| Supported Modules | Fully compatible with Modicon STB modular systems |
Industry Applications
-
Process Control–Ideal for controlling valves, actuators, and other devices requiring precise analog signals in industries like chemical, oil & gas, and power generation
-
Manufacturing Automation–Ensures consistent and accurate output for controlling various machines and systems on production lines
-
Building Automation–Used in HVAC systems to control temperature and air quality devices with high precision
-
Water Treatment–Controls pumps, valves, and other process equipment for optimized water and wastewater treatment operations
-
Renewable Energy–Used in solar and wind energy systems to control and monitor output parameters
The Schneider STBACO0220 Standard Analog Output Module offers precision, flexibility, and reliability for a wide range of industrial automation applications. With its robust design and easy integration into Schneider Electric’s Modicon STB I/O systems, this module ensures consistent performance and control in demanding environments. Whether used in process control, automation, or machine monitoring, the STBACO0220 is a reliable choice for maintaining system accuracy and stability.
