The Bently Nevada 18745-03 is a 5mm / 8mm Proximitor Sensor in the 7200 Series. It is a non-contacting, gap-to-voltage transducer system that measures both static and dynamic distances between the probe tip and the observed target. The sensor has a range of 5mm to 8mm and an accuracy of ±25µm. It is also side-shielded to reduce the effects of target misalignment.

Applications

Vibration Monitoring: The sensor measures the vibration of rotating machinery like pumps, motors, and turbines. This information helps in detecting and diagnosing faults in the machinery.

Position Monitoring: The sensor measures the position of objects such as shafts, gears, and valves. This data aids in machinery control and provides feedback to operators.

Gap Measurement: The sensor measures the gap between two objects, such as the clearance between a bearing and a shaft. This ensures proper machinery alignment and prevents wear and tear.

Key Features

• Non-contacting measurement
• 5mm to 8mm range
• ±25µm accuracy
• Side-shielded for reduced sensitivity to target misalignment
• Rugged and reliable
• IP67 rated
• CE marked
• ATEX Zone 0 hazardous area approved

Technical Specifications

Power Supply: 24 VDC

Output Signal: 4-20 mA

Operating Temperature: -40°C to +125°C

Humidity: 0% to 95% RH, non-condensing

Vibration: 20g RMS, 50 Hz to 2 kHz

Shock: 50g, half-sine, 20 msec duration

Weight: 400g

Material: Stainless steel

Connector: M12 connector
