The Epro PR6424/002-030+CON021 16mm Eddy-Current Sensor is a precision non-contact displacement sensor designed for high-accuracy measurement of shaft vibration and position in rotating machinery. This 16 mm sensor provides reliable, real-time data to support condition monitoring, machinery protection, and predictive maintenance.

Key Features

• Non-contact measurement of displacement and vibration

• 16 mm probe diameter for enhanced sensitivity

• High-accuracy and repeatable measurements

• Rugged industrial design for harsh environments

• Compatible with Epro monitoring systems

• Supports predictive maintenance and machinery protection

• Easy installation with standard connectors

Technical Specifications

Industry Applications

• Power Generation – turbine and generator vibration monitoring

• Oil & Gas – compressors, pumps, and rotating machinery

• Petrochemical & Chemical – critical machinery protection

• Manufacturing – large motor and gearbox monitoring

• Water & Wastewater – pump and motor condition monitoring

Advantages

• Provides accurate, real-time displacement measurement for machinery protection

• Rugged design suitable for extreme industrial conditions

• Easy integration with Epro monitoring systems

• Supports predictive maintenance to reduce unplanned downtime

• High repeatability and long-term stability

• Compact and durable for flexible installation

Frequently Asked Questions (FAQ)

Q1: What is the primary function of this sensor?

It measures non-contact displacement and vibration to protect machinery and optimize performance.

Q2: What is the probe diameter?

16 mm.

Q3: What is the measurement range?

±0.030 in (0.76 mm).

Q4: What type of output does it provide?

Differential voltage.

Q5: What is the operating temperature range?

-40 °C to +125 °C.

Q6: Is it suitable for humid environments?

Yes, rated for up to 100% condensing humidity.

Q7: How is the sensor mounted?

It supports threaded or flange mounting.

Q8: What connector is integrated with the sensor?

It comes with a CON021 connector.

Q9: Is it CE and RoHS compliant?

Yes.

Q10: Which industries commonly use this sensor?

Power generation, oil & gas, petrochemical, manufacturing, and water & wastewater.
