The Ovation 1D54540G01 AC Distribution Panel is a crucial component in industrial power distribution systems, particularly for AC power distribution and circuit protection in complex automation and control environments. Designed and manufactured by Emerson, this panel ensures safe, reliable, and efficient power distribution for various critical processes across industries such as energy, oil and gas, chemical plants, and manufacturing.

The Ovation 1D54540G01 AC Distribution Panel features a modular design, allowing for flexible configuration and customization to meet the unique needs of each installation. This distribution panel is equipped with high-performance fuses, circuit breakers, and load breakers, offering superior protection against short circuits, overloads, and other electrical faults.

With a compact form factor of 222 x 125 x 30 mm and a weight of just 0.6 kg, this AC Distribution Panel is designed to fit seamlessly into tight enclosures and can be easily integrated into control systems with minimal effort.

Product Specifications

Product Applications

The Ovation 1D54540G01 AC Distribution Panel is designed for use in various industrial applications, including:

1. Industrial Power Distribution

   The panel ensures safe and reliable power distribution to critical equipment within control systems, machines, and plants. It provides efficient power supply management, minimizing downtime and protecting sensitive equipment from electrical faults.

2. Process Automation

   It is extensively used in automation control panels, providing stability and protection to systems responsible for process control, data acquisition, and system integration in industries like chemical, pharmaceutical, and automotive manufacturing.

3. Energy Plants

   In power generation plants, it ensures stable electrical supply to sensitive systems such as turbine generators, compressors, and other plant equipment, enabling continuous operations without compromising safety.

4. Oil & Gas

   This AC Distribution Panel is critical for offshore oil rigs, refineries, and processing plants where reliable electrical power is essential for pumps, valves, control panels, and automation systems.

5. HVAC and Electrical Equipment

   The panel provides protection and power distribution in HVAC systems, electrical cabinets, and other machinery, ensuring continuous operation even in demanding environmental conditions.

6. Renewable Energy Systems

   It is also used in solar power plants, wind turbine systems, and other renewable energy installations, where consistent and safe power distribution is critical for the efficiency of the system.

Product Advantages

1. Compact Design

   The Ovation 1D54540G01 AC Distribution Panel features a compact and space-saving design that is ideal for installations where space constraints are a consideration, such as in panelboards or control enclosures.

2. High Current Rating

   With a current rating range from 10A to 100A, the panel is suitable for various industrial power needs, supporting both low and high-power applications.

3. Robust Protection Features

   Equipped with thermal-magnetic or electronic circuit breakers, the Ovation 1D54540G01 offers exceptional protection against overloads, short circuits, and ground faults, ensuring maximum safety for connected devices and equipment.

4. Easy Integration

   The modular design and panel-mounting feature allow easy integration into existing systems, whether upgrading or replacing older distribution panels.

5. Energy Efficiency

   By ensuring that electrical systems operate within safe parameters, the panel helps optimize the energy consumption of connected machinery, reducing the chances of unnecessary energy losses.

6. Compliance and Certifications

   The panel complies with UL standards and is CE marked, providing assurance that it meets global safety standards and quality assurance protocols, which is crucial for industries requiring high standards of safety and reliability.

FAQ

1. What is the nominal voltage of the Ovation 1D54540G01 AC Distribution Panel?

   The Ovation 1D54540G01 AC Distribution Panel supports 120/240V AC nominal voltage.

2. What is the current rating range of this distribution panel?

   The current rating for this panel ranges from 10A to 100A.

3. How does the Ovation AC Distribution Panel protect against faults?

   It features thermal-magnetic or electronic circuit breakers for overload, short-circuit, and ground fault protection.

4. What type of material is used in the construction of the panel?

   The panel is made of powder-coated steel, ensuring durability and corrosion resistance.

5. What type of mounting is supported by this panel?

   The Ovation 1D54540G01 is designed for panel-mounting.

6. What industries can benefit from the Ovation AC Distribution Panel?

   Industries such as oil & gas, power generation, automation, and manufacturing benefit from this panel’s capabilities.

7. What is the frequency range supported by the Ovation 1D54540G01?

   It operates within a frequency range of 50 Hz to 60 Hz.

8. Is this panel suitable for use in high-power applications?

   Yes, it is designed to handle applications with a current range of up to 100A, suitable for high-power industrial applications.

9. Does this panel meet any international standards?

   Yes, the Ovation 1D54540G01 meets UL and CE standards, ensuring global safety and compliance.

10. Can the Ovation AC Distribution Panel be integrated into existing systems?

    Yes, the panel’s modular design and panel-mounting options make it easy to integrate into existing control and distribution systems.
