The GE IC693PIF400 is an industrial-grade Power Interface (PI) Module designed for use within the GE Fanuc Series 90-30 Programmable Logic Controller (PLC) system. This module functions as a bridge between an external power supply and various field I/O devices. It provides isolation, regulation, and conditioned power delivery to other modules or external devices that require clean and reliable power sources.

Specifically tailored for high-performance automation systems, the IC693PIF400 is typically used in environments where signal integrity, power filtering, and interface compatibility are essential. It allows for the integration of various field interfaces and peripheral modules into the central control system without compromising power quality or safety.

This unit is known for its durability, compact form factor, and system compatibility with GE’s legacy control platforms, making it ideal for upgrades, retrofits, or expansions in both legacy and modern industrial automation systems.

Product Specifications

Product Applications

• Industrial Automation Systems: Used as a power interface within PLC systems controlling motors, drives, valves, and process sensors.

• Manufacturing Plants: Provides reliable power conditioning and distribution for various field devices.

• Process Control: Supports continuous process automation systems where input power must be filtered and stabilized.

• Energy & Utilities: Facilitates secure interface between external power sources and monitoring/control I/O.

• Retrofitting Legacy Systems: Ideal for upgrading older Series 90-30 systems with improved power management.

• OEM Equipment Integration: Used in custom-built machinery for PLC-powered subsystem integration.

Product Advantages

• Power Isolation: Protects control systems from power anomalies and field-originated interference.

• Compact Design: Easily fits into standard GE 90-30 PLC racks without requiring additional real estate.

• System Compatibility: Fully integrates with the GE 90-30 PLC platform and supports a wide range of modules.

• Ease of Installation: Plug-and-play design for fast deployment, maintenance, or replacement.

• LED Indicators: Provides at-a-glance monitoring of power and operational status.

• High Reliability: Engineered for long-term performance in industrial environments.

• Cost-Effective: Offers power interfacing at a fraction of the cost of external power conditioning hardware.

• Maintenance Friendly: Modular design allows easy access and replacement without disturbing neighboring modules.

Frequently Asked Questions (FAQ)

1. What is the primary function of the IC693PIF400 module?

   It serves as a power interface, delivering isolated and conditioned 24V DC power to field devices or I/O modules.

2. Which PLC series is it compatible with?

   It is specifically designed for the GE Fanuc Series 90-30 PLC system.

3. Does the IC693PIF400 provide communication features?

   No, it is a passive power module without communication capabilities.

4. How is the module mounted?

   It is installed in a standard slot on the 90-30 PLC baseplate.

5. What type of power input does it accept?

   It operates with a nominal 24V DC input voltage.

6. Can this module be used with analog or digital I/O cards?

   Yes, it can support power supply needs for both analog and digital interface cards in the 90-30 family.

7. Is the power output regulated and isolated?

   Yes, the module conditions and isolates the power it supplies to protect downstream modules.

8. Does it have any visual status indication?

   Yes, the front panel includes LED indicators for power status.

9. Is the IC693PIF400 suitable for hazardous environments?

   It is not intrinsically safe but is built for industrial-grade use in controlled environments.

10. What are the physical dimensions of this module?

    It measures 130 x 100 x 50 mm and weighs 0.113 kg.
