The Emerson KJ3222X1-BA1+KJ4001X1-CC1 Input Module with Terminal Blocks is a high-reliability S-series input module designed for the Emerson DeltaV distributed control system (DCS). This module, when paired with its dedicated terminal block, provides secure, isolated, and accurate acquisition of process signals from field devices.

The KJ3222X1-BA1 serves as the input module, designed to capture digital or frequency-based signals, while the KJ4001X1-CC1 terminal block ensures safe and robust wiring connections between the control system and external devices. Together, they deliver a highly integrated solution for process automation applications that demand dependable performance and ease of maintenance.

Product Specifications

Product Applications

The KJ3222X1-BA1+KJ4001X1-CC1 is designed for diverse industrial applications where reliable signal acquisition is essential:

• Digital Signal Monitoring: Acquires discrete signals from switches, relays, and contactors.

• Frequency-Based Measurement: Captures signals from pulse/frequency transmitters, such as flow meters and speed sensors.

• Process Monitoring: Interfaces with field devices for accurate status monitoring and process control.

• Energy and Utility Monitoring: Collects pulse outputs from meters and sensors for energy management systems.

• Industrial Automation: Provides reliable digital input acquisition for logic execution and machine control.

• Safety and Redundancy Systems: Supports redundant input configurations for mission-critical processes.

Product Advantages

The Emerson KJ3222X1-BA1+KJ4001X1-CC1 Input Module with Terminal Blocks offers several key advantages:

• High Accuracy: Ensures precise capture of digital and frequency input signals.

• Rugged Reliability: Built to operate in harsh industrial environments with strong noise immunity.

• Hot-Swappable: Can be replaced during system operation without process interruption.

• Diagnostics Capability: Provides self-checks, error detection, and channel status indicators.

• Redundancy Support: Compatible with redundant configurations for high system availability.

• Ease of Wiring: Terminal block design simplifies field wiring and reduces installation time.

• Seamless Integration: Fully compatible with DeltaV architecture for straightforward configuration.

• Flexibility: Supports a variety of input sources including frequency transmitters and digital contacts.

FAQ

1. How many input channels are provided by the KJ3222X1-BA1?

   The module provides 16 isolated input channels.

2. What type of signals can this input module handle?

   It supports both digital and frequency-based input signals.

3. What is the maximum supported frequency input?

   The module supports input frequencies up to 10 kHz.

4. Does the module provide galvanic isolation?

   Yes, galvanic isolation is provided between input channels and between the channels and system bus.

5. Can the module be hot-swapped during operation?

   Yes, it is hot-swappable, allowing replacement without system shutdown.

6. How are diagnostic errors communicated?

   Errors are reported via DeltaV system diagnostics and local LED indicators.

7. Does the module support redundant configuration?

   Yes, it can be deployed in redundant setups for enhanced reliability.

8. What type of wiring is supported by the KJ4001X1-CC1 terminal block?

   It supports secure screw-type connections for field wiring and provides robust signal integrity.

9. How is the module powered?

   Power is provided through the DeltaV backplane, eliminating the need for external power.

10. Which types of field devices can be connected?

    Devices such as flow meters, counters, switches, relays, and speed sensors can be connected.
