With enhanced isolation, LED status indicators, and solid-state output design, it allows for reliable operation, long service life, and reduced maintenance. The module supports both sourcing and sinking output configurations and conforms to the highest industry standards in terms of electromagnetic compatibility and environmental durability.

Technical Specifications

Product Advantages

1. High-Speed Switching

   Capable of operating with fast response times, ensuring compatibility with time-sensitive control systems.

2. Compact and Modular

   The module offers 16 outputs in a space-saving form factor, making it ideal for modular PLC racks.

3. Diagnostic Capabilities

   Integrated diagnostic features such as fault detection, open circuit notification, and individual channel status LEDs reduce downtime and maintenance complexity.

4. Solid-State Reliability

   Uses solid-state components for outputs, which offer a longer operational lifespan than mechanical relays and reduce wear and tear.

5. Integrated Protection

   Includes protection against short-circuiting and overcurrent, improving system robustness.

6. Wide Application Flexibility

   The 140DDO15310C supports a broad range of control tasks in different industries due to its versatile DC output design.

7. Easy Integration

   Seamless compatibility with Modicon Quantum processors and programming environments (such as Unity Pro/ EcoStruxure Control Expert).

Applications

• Industrial Automation – Used for controlling actuators, valves, and solenoids in process automation.

• Manufacturing Plants – Ideal for discrete control tasks in assembly lines and material handling systems.

• Power Generation – Supports turbine control, breaker logic, and signal control tasks.

• Oil and Gas – Used in remote terminal units (RTUs) for output signal management.

• Water Treatment Facilities – Provides output control for pumps, mixers, and gate actuators.

• Transportation and Infrastructure – Suitable for output control in smart transportation systems and utility networks.

Frequently Asked Questions (FAQ)

Q1: What is the main function of the 140DDO15310C module?

A1: It functions as a 16-channel discrete output module that outputs 24 VDC signals for controlling devices such as solenoids, actuators, and relays.

Q2: Can this module handle both sourcing and sinking outputs?

A2: No, this specific module is designed for sourcing outputs only. Load connections should be made accordingly.

Q3: How does the module indicate a fault or failure?

A3: Each channel has an LED indicator for status, and the module includes internal diagnostics for detecting short circuits or open circuits.

Q4: What is the isolation voltage provided by the module?

A4: The module offers an isolation of 1780 Vrms between the channels and the backplane.

Q5: What software is compatible with the 140DDO15310C?

A5: The module can be configured and managed through Schneider Electric’s Unity Pro or EcoStruxure Control Expert.

Q6: Can this module be hot-swapped?

A6: Yes, the 140DDO15310C supports hot-swapping when used in a Quantum rack with proper safety and grounding.

Q7: Is this module RoHS compliant?

A7: Yes, it complies with RoHS and other international environmental standards.

Q8: What is the maximum output current per channel?

A8: Each channel can deliver up to 0.5 A at 24 VDC.

Q9: What protection features are built into the outputs?

A9: Each output is protected against short-circuits and overcurrent conditions.

Q10: How should the module be mounted?

A10: It should be inserted into a Modicon Quantum backplane and secured with module clamps. Proper wiring and shielding should be followed as per installation guidelines.
