General Electric IS200VTCCH1CBB Thermocouple Processor Board

The GE IS200VTCCH1CBB is a thermocouple processor board designed to interface with industrial control systems, particularly in the Speedtronic turbine control series. This board processes input signals from thermocouples, converting them into readable temperature data for monitoring and controlling industrial processes. With its ability to support a wide range of thermocouple types, it is an essential component in many power generation, manufacturing, and industrial automation systems.

The IS200VTCCH1CBB ensures accurate and real-time processing of temperature measurements, which are crucial for applications that rely on precise temperature regulation. Whether used for turbine monitoring, combustion control, or other temperature-sensitive processes, this board helps ensure operational efficiency and safety. It measures 82.6 × 41.9 mm and weighs just 0.45 kg, making it compact and easy to integrate into VME-based control systems.

Product Parameters

Product Applications

The GE IS200VTCCH1CBB Thermocouple Processor Board is used in a variety of industrial and automation applications that require accurate temperature measurement and control. Some of the key applications include:

• Turbine Control Systems: Used to monitor and control turbine temperatures, the IS200VTCCH1CBB helps ensure turbines operate within safe temperature ranges, preventing damage and optimizing performance.

• Power Generation: In power plants, this board processes temperature data from thermocouples installed in critical components such as boilers, turbines, and generators, enabling real-time monitoring and control.

• Industrial Automation: The IS200VTCCH1CBB supports temperature regulation in automated systems, ensuring consistent processing conditions for manufacturing and production lines.

• Combustion Control: The board can be integrated into combustion control systems to monitor temperatures in combustion chambers, preventing overheating and ensuring efficient fuel usage.

• Oil and Gas: In the oil and gas industry, the IS200VTCCH1CBB is used to monitor and control temperatures in critical equipment, helping to ensure safe and efficient operations.

• Process Control: In chemical and petrochemical processes, the board plays a crucial role in ensuring that temperature-sensitive processes are accurately monitored and controlled.

Product Advantages

• High-Accuracy Signal Conversion: The IS200VTCCH1CBB offers precise signal conversion from thermocouples, ensuring accurate temperature readings and reliable system operation.

• Wide Input Range: This processor supports a wide range of thermocouple types, making it versatile and adaptable for different applications. It can measure temperatures from -200°C to 1800°C.

• Compact Design: With its 82.6 × 41.9 mm form factor and 0.45 kg weight, the IS200VTCCH1CBB is compact and easy to integrate into existing VME-based control systems.

• Reliable Operation in Harsh Environments: With an operating temperature range of -40°C to 70°C, the board is suitable for use in industrial environments that experience extreme temperature fluctuations.

• Flexible Integration: The IS200VTCCH1CBB is designed to plug into VME chassis, allowing for easy integration with other system components and simplifying installation and maintenance.

• High-Speed Processing: The board processes thermocouple inputs in real-time, enabling rapid response times and ensuring the efficient operation of critical processes.

• Durable and Long-Lasting: The IS200VTCCH1CBB is built to withstand harsh industrial environments, offering a long operational life and minimal maintenance.

FAQ (Frequently Asked Questions)

1. What is the primary function of the GE IS200VTCCH1CBB Thermocouple Processor Board?

The IS200VTCCH1CBB is a thermocouple processor that converts thermocouple input signals into readable temperature data for monitoring and control of industrial processes.

2. What types of thermocouples are supported by the IS200VTCCH1CBB?

The board supports a wide variety of thermocouple types, including Type J, K, T, E, and more, providing flexibility for different temperature measurement needs.

3. What is the input range for the IS200VTCCH1CBB?

The IS200VTCCH1CBB can measure temperatures from -200°C to 1800°C, depending on the type of thermocouple used.

4. What is the size and weight of the IS200VTCCH1CBB?

The board has dimensions of 82.6 × 41.9 mm and weighs 0.45 kg, making it compact and lightweight for easy integration into control systems.

5. What is the operating temperature range of the IS200VTCCH1CBB?

The board can operate within a temperature range of -40°C to 70°C, making it suitable for use in harsh industrial environments.

6. How does the IS200VTCCH1CBB ensure accurate temperature measurement?

The board provides high-accuracy signal conversion from thermocouples, ensuring that temperature readings are precise and reliable.

7. How is the IS200VTCCH1CBB mounted?

The IS200VTCCH1CBB is plugged into a VME chassis, allowing for easy installation and integration with other system components.

8. What industries use the IS200VTCCH1CBB?

The board is commonly used in turbine control, power generation, industrial automation, combustion control, and oil and gas industries, where temperature monitoring is critical.

9. What voltage does the IS200VTCCH1CBB require?

The board operates on 5V DC and 3.3V DC, which are standard for modern industrial control systems.

10. Can the IS200VTCCH1CBB be integrated with other GE components?

Yes, the IS200VTCCH1CBB is compatible with other components in the GE Speedtronic and VME-based systems, allowing for seamless integration into existing control systems.
