Vibro-Meter IQS450 204-450-000-002 A1-B23-H10-I0 Signal Conditioner
Item Number: IQS450 204-450-000-002 A1-B23-H10-I0
Brand: Vibro-Meter
Lead Time: In stock
Description:Signal Conditioner
Payment: T/T
Product Description
IQS450204-450-000-002 A1-B23-H10-I0 signal conditioner is a device that acts on the drive sensor and converts the signal to a standard voltage/current output. Together with the TQ401 non-contact sensor, it forms a calibrated proximity measurement system.
The system outputs a voltage or current proportional to the distance between the sensor probe and the target (such as a machine shaft), which can achieve non-contact measurement of the relative displacement of moving mechanical parts.
Function&Features
Non-contact measurement
- Based on the eddy current effect, measure the gap between the metal shaft and the probe (0.1~50mm typical range, depending on the model).
- Linear output: voltage/current signal is strictly proportional to the gap change (such as 4-20mA corresponds to 0-2mm).
High-frequency modulation and demodulation (HF Modem)
- The signal conditioner (IQS450) has a built-in high-frequency drive circuit.
- Aluminum housing, shielding electromagnetic noise.
Specifications
|
Parameter |
Value |
|
Voltage output, 3 - wire configuration |
|
|
Voltage at min. GAP |
-1.6 V |
|
Voltage at max. GAP |
-17.6 V |
|
Dynamic range |
16 V |
|
Output impedance |
500 Ω |
|
Short - circuit current |
45 mA |
|
Current output, 2 - wire configuration |
|
|
Current at min. GAP |
-15.5 mA |
|
Current at max. GAP |
-20.5 mA |
|
Dynamic range |
5 mA |
|
Output capacitance |
1 nF |
|
Output inductance |
100 μH |
FAQs
Q: What is the brand?
A: Others
Q: What is the type?
A:Signal Conditioner
Q: What is the warranty?
A: 1 year
Q: Where is the shipping lovation?
A: Xiamen
Q: What is the payment method?
A: T/T
Q: Why choose us?
A: We are the supplier for industrial automation spare parts,We speciaized in PLC DCS and TSl system modules and spare parts for 10 years, With our professional expertise and extensive experience, we are well-equipped to meet your requirements.
