General Electric IC697BEM733D Industrial Ethernet Communication Module

The GE IC697BEM733D is a flagship Ethernet communication module in GE’s Series 90-70 PLC lineup, engineered to serve as the critical “network gateway” for large-scale industrial automation systems. Unlike basic communication modules, the GE IC697BEM733D integrates multi-protocol support and gigabit Ethernet ports, enabling seamless data transfer between Series 90-70 controllers and upstream devices (e.g., SCADA systems, HMIs, MES platforms) or downstream components (e.g., remote I/O, servo drives).

Technical positioning for high-demand applications (e.g., power generation, heavy manufacturing), the GE IC697BEM733D eliminates communication bottlenecks common in legacy modules. It supports dual-port redundancy, ensuring network continuity if one port fails—critical for processes where unplanned downtime is costly. In automation architectures, the GE IC697BEM733D acts as a “data router,” translating protocols (e.g., PROFINET to Modbus TCP/IP) and synchronizing real-time control data, making it indispensable for integrated, plant-wide automation.

Detailed Parameter Table

Core Advantages and Technical Highlights

Multi-protocol versatility: The GE IC697BEM733D natively supports four industrial protocols (PROFINET RT, EtherNet/IP, Modbus TCP/IP, GE SRTP), eliminating the need for external protocol converters. For example, in an automotive factory, it can connect a Series 90-70 PLC (using SRTP) to PROFINET-based robotic arms and EtherNet/IP-enabled HMIs—all via a single GE IC697BEM733D. This reduces hardware costs and simplifies network management.

Gigabit speed and redundancy: Equipped with 10/100/1000 Mbps ports, the GE IC697BEM733D delivers data transfer rates up to 10x faster than 100 Mbps modules, ideal for high-volume data applications (e.g., real-time video monitoring of production lines). Its dual-port design supports RSTP/STP protocols, enabling automatic failover (≤50 ms) if a network link is disrupted—ensuring uninterrupted communication in critical systems like power plant turbine control.

Seamless Series 90-70 integration: Optimized for Series 90-70 chassis, the GE IC697BEM733D leverages the platform’s high-speed backplane (up to 160 Mbps) for low-latency data exchange with the PLC CPU. It draws power directly from the chassis, eliminating the need for external power supplies and reducing cable clutter in control cabinets. Configuration is done via GE’s Proficy Machine Edition software, with pre-built templates for common protocols—cutting setup time by 30% compared to generic modules.

Robust industrial design: The GE IC697BEM733D is built to withstand harsh industrial environments, with a wide operating temperature range (0°C-60°C) and resistance to vibration (5 g peak) and shock (30 g peak). It also features EMC compliance (EN 61000-6-2) to shield against electrical noise from nearby motors or variable frequency drives (VFDs)—ensuring stable communication in noisy settings like steel mills.

Typical Application Scenarios

In power generation (e.g., coal-fired plants), the GE IC697BEM733D is central to turbine control systems. It connects a IC697CPU780 PLC to PROFINET-based vibration sensors (monitoring turbine health) and Modbus TCP/IP-enabled SCADA systems (for remote monitoring by plant operators). The module’s gigabit speed ensures real-time transmission of vibration data (critical for predicting equipment failure), while dual-port redundancy prevents communication loss during network maintenance—avoiding costly turbine shutdowns.

For heavy machinery manufacturing (e.g., excavator production), the GE IC697BEM733D links Series 90-70 PLCs to EtherNet/IP-enabled servo drives and HMIs. It synchronizes control signals (e.g., for robotic welding arms) with production data (e.g., weld quality metrics) via SRTP, enabling the PLC to adjust parameters in real time. The module’s multi-protocol support eliminates the need for separate modules for drives and HMIs, reducing control cabinet footprint by 20%.

In oil refineries, the GE IC697BEM733D enables distributed control of distillation columns. It connects local temperature/pressure sensors (via Modbus TCP/IP) to a central Series 90-70 PLC, transmitting data to a SCADA system for process visualization. Its rugged design withstands the refinery’s high-temperature, dusty environment, while short-circuit protection on Ethernet ports prevents damage from accidental wire grounding—ensuring reliable operation in hazardous conditions.
